DTMF MEMORY
CLONE MODE
CALL CHANNEL (p. 35)
WEATHER CHANNEL (p. 83)*
2
BANK CHANNEL (p. 32)CHANNEL NAME
INDICATION (p. 29)
MEMORY MODE (p. 24)
VFO mode (p. 9)
When the DTMF
memory encoder is
activated.
See p. 45 for details.
See p. 86 for details.
for 1 sec.
*
1
Appears when accessing from memory mode only.
*
2
Available for USA versions only.
*
3
Appears in some version only.
ANM
MONI
for 1 sec.
ANM
MONI
OPT
BANK
OPT
BANK
SCAN
V/MHz
PRIO
M/CALL
SCAN
V/MHz
LOCK
SET
T-SCAN
TONE
SCAN
V/MHz
PRIO
M/CALL
93
MODE ARRANGEMENT
