5 MEMORY OPERATION
■ Memory clearing
Contents of programmed memories can be cleared (blanked),
if desired.
q Push [V/MHz ] to select VFO mode.
w Push [S.MW ] momentarily.
•“M” indicator and the memory channel number blink.
e Rotate [DIAL] to select the memory channel to be cleared.
• Memory channels not yet programmed are blank.
r Push [S.MW ] momentarily, then push [S.MW ]
again for 1 sec.
☞ This operation must be performed within 1.5 sec.
• 3 beeps sound, then the frequency is cleared.
•“M” indicator blinks continuously.
• When clearing the call channel, the current VFO conditions are
re-programmed into the call channel automatically.
t Push any key, except [S.MW ], to return to VFO
mode.
NOTE: Be careful!— the contents of cleared memories
CANNOT be recalled.
MW
MWMW
MW
SCAN
[EXAMPLE]: Clearing memory channel 20.
