5 MEMORY OPERATION
■ Memory bank setting
q Push [M/CALL ] to select memory mode, then se-
lect the desired memory channel via [DIAL].
w Push [SET ] enter the set mode.
e Push [SET] or [MONI] several times until “BAK” appears.
• “– –” indication blinks as follows.
r Rotate [DIAL] to select the desired bank to be set.
t Push any key other than [SET] or [MONI] to set the chan-
nel into the bank and return to regular memory condition.
y Repeat steps q to t to set another memory channel into
the same or another bank.
z Push [MR/CALL] then select the desired
memory channel via [
YY
]/[
ZZ
] or keypad.
x Push [
SET
B(D-OFF)] to enter set mode.
c Push [
SET
B(D-OFF)] or [
ENT
C(T-OFF)]
several times until “BAK” appears.
v Push [
YY
] or [
ZZ
] to select the desired bank
to be set.
b Push [
CLR
A(MW)] to set the channel into
the bank and exit set mode.
n Repeat steps z to b to set an another
memory channel into the same or another
bank.
BANK/OPTION
MW
[Y]/[Z]
LOCK
S
E
T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
[DIAL]
LOCK
S
E
T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
LOCK
PRIO
