■ Repeater operation
1. Setting duplex
Push [LOW ] for 1 sec. once or twice to select minus
duplex or plus duplex.
• The USA version has an auto repeater function, therefore, setting
duplex is not required.
2. Repeater tone
Push [TONE ] several times until “ ” appears, if the
repeater requires a subaudible to be accessed.
Using the HM-133V
Plus or minus duplex selection and the repeater tone setting
can be made easily via HM-133V.
Push [
DUP
– 7(TONE)] for minus duplex; [
DUP
+ 8(TSQL
SS
)]
for plus duplex selection, push [FUNC] then [
DUP
– 7(TONE)]
to turn the repeater tone ON.
