Makita RT0700C 171192 (171192) [11/88] Circular work

Fig.8

Secure the templet to the workpiece. Place the tool on

the templet and move the tool with the templet guide

sliding along the side of the templet.

Fig.9

NOTE:

• The workpiece will be cut a slightly different size

from the templet. Allow for the distance (X)

between the router bit and the outside of the

templet guide. The distance (X) can be calculated

by using the following equation:

Distance (X) = (outside diameter of the templet guide -

router bit diameter) / 2

Straight guide (optional accessory)

Fig.10

The straight guide is effectively used for straight cuts

when chamfering or grooving.

Fig.11

Attach the guide plate to the straight guide with the bolt

and the wing nut.

Fig.12

Attach the straight guide with the clamp screw (A).

Loosen the wing nut on the straight guide and adjust the

distance between the bit and the straight guide. At the

desired distance, tighten the wing nut securely.

When cutting, move the tool with the straight guide flush

with the side of the workpiece.

If the distance (A) between the side of the workpiece and

the cutting position is too wide for the straight guide, or if

the side of the workpiece is not straight, the straight guide

cannot be used. In this case, firmly clamp a straight board

to the workpiece and use it as a guide against the trimmer

base. Feed the tool in the direction of the arrow.

Fig.13

Circular work

Fig.14

Circular work may be accomplished if you assemble the

straight guide and guide plate as shown in the figures.

Min. and max. radius of circles to be cut (distance

between the center of circle and the center of bit) are as

follows:

Min.: 70 mm

Max.: 221 mm

For cutting circles between 70 mm and 121 mm in radius.

For cutting circles between 121 mm and 221 mm in

radius.

Fig.15

NOTE:

• Circles between 172 mm and 186 mm in radius

cannot be cut using this guide.

Fig.16

Align the center hole in the straight guide with the center

of the circle to be cut. Drive a nail less than 6 mm in

diameter into the center hole to secure the straight guide.

Pivot the tool around the nail in clockwise direction.

Trimmer guide (optional accessory)

Fig.17

Trimming, curved cuts in veneers for furniture and the

like can be done easily with the trimmer guide. The guide

roller rides the curve and assures a fine cut.

Fig.18

Install the trimmer guide on the tool base with the clamp

screw (A). Loosen the clamp screw (B) and adjust the

distance between the bit and the trimmer guide by

turning the adjusting screw (1 mm per turn). At the

desired distance, tighten the clamp screw (B) to secure

the trimmer guide in place.

Fig.19

When cutting, move the tool with the guide roller riding

the side of the workpiece.

Tilt base (optional accessory)

Tilt base (optional accessory) is convenient for

chamfering.

Fig.20

Place the tool onto the tilt base and close the locking

lever at the desired protrusion of the bit. For desired

angle, tighten the clamping screws on its sides.

Firmly clamp a straight board to the workpiece and use it

as a guide against the tilt base. Feed the tool in the

direction of the arrow.

Base protector removed from the tilt base (optional

accessory)

Mounting the base protector which has been removed

from the tilt base on the trimmer base allows the change

of the trimmer base from the round base to a square

base.

For another application, remove the base protector from

the tilt base by loosening and removing four screws.

Fig.21

And then mount the base protector on the trimmer base.

Offset base (optional accessory)

Fig.22

(1) Offset base (optional accessory) is

convenient for work in a tight area such as a

corner.

Fig.23

Before installing the tool on the offset base, remove the

collet nut and collet cone by loosening the collet nut.

Fig.24

Install the pulley on the tool by pressing the shaft lock

and firmly tightening the pulley with a wrench.

Fig.25

Place the collet cone and screw the collet nut on the

offset base as shown in the figure.

Fig.26

Mount the tool on the offset base
