ED12-321A Capacity Tables
SUPER MULTI NX B-Series Heat Pump 97
3
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
3.5+3.5 22 6.191.876.572.096.952.127.142.137.722.178.102.19
25 5.96 2.21 6.34 2.25 6.72 2.28 6.91 2.30 7.48 2.35 7.86 2.37
32 5.64 2.44 6.02 2.50 6.40 2.55 6.59 2.58 7.16 2.65 7.54 2.70
35 5.50 2.55 5.88 2.62 6.26 2.69
6.45 2.72 7.02 2.79 7.40 2.84
40 5.27 2.75 5.65 2.84 6.03 2.92 6.22 2.96 6.79 3.06 7.17 3.11
43 5.13 2.90 5.51 2.98 5.89 3.06 6.08 3.11 6.65 3.22 7.03 3.29
46 4.99 3.00 5.36 3.00 5.72 3.00 5.89 3.00 6.41 3.00 6.75 3.00
3.5+5.0 22 6.511.766.911.967.312.007.512.018.112.048.512.06
25 6.27 2.08 6.67 2.12 7.07 2.15 7.27 2.16 7.87 2.21 8.27 2.23
32 5.93 2.30 6.33 2.36 6.73 2.40 6.93 2.43 7.53 2.49 7.93 2.54
35 5.78 2.40 6.18 2.47 6.58 2.53
6.78 2.56 7.38 2.63 7.78 2.67
40 5.54 2.59 5.94 2.67 6.34 2.75 6.54 2.78 7.14 2.88 7.54 2.93
43 5.39 2.73 5.79 2.80 6.19 2.88 6.39 2.93 6.99 3.03 7.39 3.09
46 5.24 2.85 5.64 2.96 6.03 3.00 6.22 3.00 6.78 3.00 7.13 3.00
3.5+6.0 22 6.771.907.182.127.602.157.812.168.432.208.852.22
25 6.52 2.24 6.93 2.28 7.35 2.32 7.56 2.33 8.18 2.38 8.60 2.41
32 6.16 2.48 6.58 2.54 6.99 2.59 7.20 2.62 7.83 2.69 8.24 2.74
35 6.01 2.59 6.43 2.66 6.84 2.73
7.05 2.76 7.67 2.84 8.09 2.88
40 5.76 2.79 6.17 2.88 6.59 2.96 6.80 3.00 7.42 3.10 7.84 3.16
43 5.60 2.94 6.02 3.02 6.44 3.11 6.65 3.15 7.27 3.27 7.69 3.33
46 5.45 3.00 5.85 3.00 6.24 3.00 6.42 3.00 6.98 3.00 7.35 3.00
5.0+5.0 22 6.921.647.351.827.771.857.991.878.621.909.051.92
25 6.66 1.93 7.09 1.97 7.51 2.00 7.73 2.01 8.37 2.05 8.79 2.08
32 6.30 2.14 6.73 2.19 7.15 2.24 7.37 2.26 8.00 2.32 8.43 2.36
35 6.15 2.23 6.57 2.29 7.00 2.35
7.21 2.38 7.85 2.45 8.27 2.49
40 5.89 2.41 6.31 2.49 6.74 2.56 6.95 2.59 7.59 2.68 8.02 2.73
43 5.73 2.53 6.16 2.60 6.58 2.68 6.80 2.72 7.43 2.82 7.86 2.88
46 5.58 2.65 6.00 2.75 6.43 2.84 6.64 2.89 7.28 3.00 7.67 3.00
5.0+6.0 22 6.981.647.411.827.841.858.051.878.701.909.131.92
25 6.72 1.93 7.15 1.97 7.58 2.00 7.79 2.01 8.44 2.05 8.86 2.08
32 6.35 2.14 6.78 2.19 7.21 2.24 7.43 2.26 8.07 2.32 8.50 2.36
35 6.20 2.23 6.63 2.29 7.06 2.35
7.27 2.38 7.91 2.45 8.34 2.49
40 5.94 2.41 6.37 2.49 6.79 2.56 7.01 2.59 7.65 2.68 8.08 2.73
43 5.78 2.53 6.21 2.60 6.64 2.68 6.85 2.72 7.50 2.82 7.93 2.88
46 5.62 2.65 6.05 2.75 6.48 2.84 6.70 2.89 7.34 3.00 7.73 3.00
2.5+2.5+2.5 22 6.661.637.071.817.481.847.691.858.301.888.711.90
25 6.41 1.91 6.82 1.95 7.23 1.98 7.44 1.99 8.05 2.03 8.46 2.06
32 6.07 2.12 6.47 2.17 6.88 2.22 7.09 2.24 7.70 2.30 8.11 2.34
35 5.92 2.22 6.33 2.27 6.74 2.33
6.94 2.36 7.55 2.42 7.96 2.46
40 5.67 2.39 6.08 2.47 6.49 2.53 6.69 2.57 7.31 2.65 7.72 2.70
43 5.52 2.51 5.93 2.58 6.34 2.66 6.54 2.70 7.16 2.80 7.57 2.85
46 5.37 2.63 5.78 2.73 6.19 2.82 6.39 2.86 7.01 2.98 7.39 3.00
2.5+2.5+3.5 22 6.711.667.121.857.541.887.741.898.361.928.771.94
25 6.46 1.95 6.87 1.99 7.29 2.02 7.49 2.04 8.11 2.08 8.52 2.10
32 6.11 2.16 6.52 2.22 6.93 2.26 7.14 2.29 7.76 2.35 8.17 2.39
35 5.96 2.26 6.37 2.32 6.78 2.38
6.99 2.41 7.61 2.48 8.02 2.52
40 5.71 2.44 6.12 2.52 6.53 2.59 6.74 2.62 7.36 2.71 7.77 2.76
43 5.56 2.57 5.97 2.64 6.38 2.71 6.59 2.75 7.21 2.85 7.62 2.91
46 5.41 2.68 5.82 2.79 6.23 2.88 6.44 2.92 7.04 3.00 7.41 3.00
2.5+2.5+5.0 22 6.971.637.401.817.831.848.041.858.681.889.111.90
25 6.71 1.91 7.14 1.95 7.57 1.98 7.78 1.99 8.42 2.03 8.85 2.06
32 6.34 2.12 6.77 2.17 7.20 2.22 7.42 2.24 8.06 2.30 8.49 2.34
35 6.19 2.22 6.62 2.27 7.05 2.33
7.26 2.36 7.90 2.42 8.33 2.46
40 5.93 2.39 6.36 2.47 6.79 2.53 7.00 2.57 7.64 2.65 8.07 2.70
43 5.77 2.51 6.20 2.58 6.63 2.66 6.84 2.70 7.49 2.80 7.91 2.85
46 5.62 2.63 6.04 2.73 6.47 2.82 6.69 2.86 7.33 2.98 7.73 3.00
2.5+2.5+6.0 22 7.111.807.552.007.992.038.212.058.862.089.302.10
25 6.85 2.12 7.29 2.16 7.72 2.19 7.94 2.20 8.60 2.25 9.04 2.28
32 6.48 2.34 6.91 2.40 7.35 2.45 7.57 2.48 8.23 2.54 8.66 2.59
35 6.32 2.45 6.75 2.51 7.19 2.58
7.41 2.61 8.07 2.68 8.50 2.73
40 6.05 2.64 6.49 2.73 6.93 2.80 7.14 2.84 7.80 2.93 8.24 2.99
43 5.89 2.78 6.33 2.86 6.77 2.94 6.98 2.98 7.64 3.09 8.08 3.15
46 5.73 2.91 6.17 3.00 6.57 3.00 6.77 3.00 7.34 3.00 7.72 3.00
