Daikin FTKE35BVM [141/268] Electric characteristics ed12 321a
![Daikin FTKE25BVMT [141/268] Electric characteristics ed12 321a](/views2/1761711/page141/bg8d.png)
Electric Characteristics ED12-321A
136 SUPER MULTI NX B-Series Heat Pump
Heating (50 / 60Hz 220V)
3D039723#4
Combination
Units Power Supply Comp. OFM IFM
Hz Volts Min. Max. MCA MFA RLA W FLA W FLA
2.5
50/60 220 198 242
9.3
20
5.6
60 0.55
40 0.23
3.5 9.8 7.2 40 0.23
5.0 13.5 7.3 38 0.21
6.0 15.1 9.8 45 0.25
7.1 16.8 12.4 50 0.28
2.5+2.5 15.8 8.4 80 0.45
2.5+3.5 15.9 9.6 80 0.45
2.5+5.0 15.9 11.0 78 0.44
2.5+6.0 15.9 11.6 85 0.48
2.5+7.1 15.1 11.6 90 0.50
3.5+3.5 16.5 11.3 80 0.45
3.5+5.0 16.0 11.6 78 0.44
3.5+6.0 15.0 11.6 85 0.48
3.5+7.1 14.5 11.7 90 0.50
5.0+5.0 15.2 11.7 76 0.43
5.0+6.0 14.6 11.8 83 0.46
5.0+7.1 14.3 11.5 88 0.49
6.0+6.0 14.3 11.5 90 0.50
6.0+7.1 14.3 11.3 95 0.53
2.5+2.5+2.5 15.7 10.5 120 0.68
2.5+2.5+3.5 15.9 11.4 120 0.68
2.5+2.5+5.0 15.3 11.4 118 0.66
2.5+2.5+6.0 14.4 11.4 125 0.70
2.5+2.5+7.1 14.4 11.1 130 0.73
2.5+3.5+3.5 15.2 11.4 120 0.68
2.5+3.5+5.0 14.5 11.4 118 0.66
2.5+3.5+6.0 14.2 11.1 125 0.70
2.5+3.5+7.1 13.7 10.8 130 0.73
2.5+5.0+5.0 14.5 11.0 116 0.65
2.5+5.0+6.0 14.0 10.7 123 0.69
3.5+3.5+3.5 14.5 11.4 120 0.68
3.5+3.5+5.0 14.3 11.2 118 0.66
3.5+3.5+6.0 13.8 10.9 125 0.70
3.5+5.0+5.0 13.8 10.7 116 0.65
2.5+2.5+2.5+2.5 14.4 10.3 160 0.90
2.5+2.5+2.5+3.5 13.9 10.6 160 0.90
2.5+2.5+2.5+5.0 14.0 10.4 158 0.89
2.5+2.5+2.5+6.0 13.8 10.3 165 0.93
2.5+2.5+3.5+3.5 13.8 10.4 160 0.90
2.5+2.5+3.5+5.0 13.7 10.3 158 0.89
2.5+3.5+3.5+3.5 13.7 10.3 160 0.90
SYMBOLS: NOTES:
MCA : MIN. CIRCUIT AMPS (A) 1. RLA is based on the following conditions.
Power Supply: 50 / 60Hz 220V
Cooling
Indoor temp.: 27°CDB/19°CWB
Outdoor temp.: 35°CDB.
Heating
Indoor temp.: 20°CDB
Outdoor temp.: 7°CDB/6°CWB.
2. Maximum allowable voltage variation between phases is 2%.
3. Select wire size based on the value of MCA.
4. Instead of fuse, use circuit breaker.
MFA : MAX. FUSE AMPS (A)
RLA : RATED LOAD AMPS (A)
OFM : OUTDOOR FAN MOTOR
IFM : INDOOR FAN MOTOR
FLA : FULL LOAD AMPS (A)
W : FAN MOTOR RATED OUTPUT (W)
