Capacity Tables ED12-321A
58 SUPER MULTI NX B-Series Cooling Only
7.2 Capacity Correction Factor by the Length of Refrigerant Piping (Reference)
The cooling capacity of the unit has to be corrected in accordance with the length of refrigerant piping.
(The distance between the indoor unit and the outdoor unit)
<— line: For the indoor unit with capacity of 2.5 kW.>
<--- line: For the indoor unit with capacity of 3.5 kW or more.>
Notes: 1. The graph shows the factor when additional refrigerant of the proper quantity is charged.
2. If it is for the multi-type room air-conditioner, the variation of the capacity will be smaller when only one
indoor unit is in operation.
Capacity correction factor
1
5101520
30
0.9
0.8
Cooling (R22)
Piping length (m)
(R2656)
25
