Daikin FTKE35BVM [113/268] Super multi nx b series heat pump
![Daikin FTKE35BVM [113/268] Super multi nx b series heat pump](/views2/1761711/page113/bg71.png)
Capacity Tables ED12-321A
108 SUPER MULTI NX B-Series Heat Pump
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
5.0+7.1 22 8.10 2.35 8.60 2.62 9.10 2.67 9.35 2.68 10.10 2.73 10.59 2.76
25 7.80 2.77 8.30 2.83 8.80 2.87 9.05 2.89 9.79 2.95 10.29 2.98
32 7.38 3.07 7.87 3.15 8.37 3.21 8.62 3.25 9.37 3.33 9.87 3.39
35 7.19 3.21 7.69 3.29 8.19 3.38
8.44 3.42 9.19 3.51 9.69 3.57
40 6.89 3.46 7.39 3.57 7.89 3.67 8.14 3.72 8.88 3.85 9.38 3.92
43 6.63 3.24 7.08 3.24 7.52 3.24 7.73 3.24 8.35 3.24 8.77 3.24
46 6.20 2.96 6.58 2.96 6.95 2.96 7.13 2.96 7.68 2.96 8.05 2.96
6.0+6.0 22 8.15 2.28 8.65 2.54 9.15 2.58 9.40 2.60 10.16 2.64 10.66 2.67
25 7.85 2.68 8.35 2.74 8.85 2.78 9.10 2.80 9.85 2.85 10.35 2.89
32 7.42 2.97 7.92 3.05 8.42 3.11 8.67 3.14 9.42 3.22 9.93 3.28
35 7.24 3.11 7.74 3.19 8.24 3.27
8.49 3.31 9.24 3.40 9.74 3.46
40 6.93 3.35 7.43 3.46 7.93 3.56 8.19 3.60 8.94 3.72 9.44 3.79
43 6.71 3.24 7.17 3.24 7.62 3.24 7.84 3.24 8.49 3.24 8.93 3.24
46 6.31 2.96 6.71 2.96 7.09 2.96 7.28 2.96 7.84 2.96 8.23 2.96
6.0+7.1 22 8.12 2.35 8.62 2.61 9.12 2.66 9.37 2.67 10.12 2.72 10.62 2.75
25 7.82 2.77 8.32 2.82 8.82 2.86 9.07 2.88 9.82 2.94 10.32 2.97
32 7.39 3.06 7.89 3.14 8.39 3.20 8.64 3.24 9.39 3.32 9.89 3.38
35 7.21 3.20 7.71 3.28 8.21 3.37
8.46 3.41 9.21 3.50 9.71 3.56
40 6.91 3.45 7.41 3.56 7.91 3.66 8.16 3.71 8.91 3.83 9.41 3.90
43 6.65 3.24 7.11 3.24 7.53 3.24 7.74 3.24 8.38 3.24 8.80 3.24
46 6.22 2.96 6.60 2.96 6.98 2.96 7.16 2.96 7.71 2.96 8.08 2.96
2.5+2.5+2.5 22 7.231.907.672.128.122.158.342.169.012.209.452.22
25 6.96 2.24 7.40 2.28 7.85 2.32 8.07 2.33 8.74 2.38 9.18 2.41
32 6.58 2.48 7.03 2.54 7.47 2.59 7.69 2.62 8.36 2.69 8.80 2.74
35 6.42 2.59 6.86 2.66 7.31 2.73
7.53 2.76 8.20 2.84 8.64 2.88
40 6.15 2.79 6.59 2.88 7.04 2.96 7.26 3.00 7.93 3.10 8.37 3.16
43 5.99 2.94 6.43 3.02 6.88 3.11 7.10 3.15 7.75 3.24 8.16 3.24
46 5.81 2.96 6.23 2.96 6.62 2.96 6.82 2.96 7.39 2.96 7.76 2.96
2.5+2.5+3.5 22 7.602.118.072.358.542.388.772.409.472.449.942.47
25 7.32 2.48 7.79 2.53 8.25 2.57 8.49 2.59 9.19 2.64 9.66 2.67
32 6.92 2.75 7.39 2.82 7.86 2.87 8.09 2.90 8.79 2.98 9.26 3.04
35 6.75 2.87 7.22 2.95 7.69 3.02
7.92 3.06 8.62 3.14 9.09 3.20
40 6.47 3.10 6.93 3.20 7.40 3.29 7.64 3.33 8.34 3.44 8.80 3.50
43 6.30 3.24 6.75 3.24 7.20 3.24 7.42 3.24 8.05 3.24 8.45 3.24
46 6.02 2.96 6.41 2.96 6.81 2.96 6.99 2.96 7.57 2.96 7.94 2.96
2.5+2.5+5.0 22 7.84 2.03 8.33 2.26 8.81 2.30 9.05 2.31 9.77 2.36 10.26 2.38
25 7.55 2.39 8.03 2.44 8.52 2.48 8.76 2.49 9.48 2.54 9.96 2.57
32 7.14 2.65 7.62 2.71 8.10 2.77 8.35 2.80 9.07 2.87 9.55 2.93
35 6.96 2.77 7.45 2.84 7.93 2.92
8.17 2.95 8.89 3.03 9.38 3.08
40 6.67 2.98 7.15 3.08 7.64 3.17 7.88 3.21 8.60 3.32 9.08 3.38
43 6.50 3.14 6.98 3.23 7.44 3.24 7.66 3.24 8.30 3.24 8.73 3.24
46 6.26 2.96 6.68 2.96 7.10 2.96 7.30 2.96 7.91 2.96 8.29 2.96
2.5+2.5+6.0 22 8.27 2.18 8.77 2.43 9.28 2.47 9.54 2.49 10.30 2.53 10.81 2.55
25 7.96 2.57 8.47 2.62 8.97 2.66 9.23 2.68 9.99 2.73 10.50 2.76
32 7.52 2.84 8.03 2.92 8.54 2.98 8.80 3.01 9.56 3.09 10.07 3.14
35 7.34 2.98 7.85 3.05 8.36 3.13
8.61 3.17 9.37 3.26 9.88 3.31
40 7.03 3.21 7.54 3.31 8.05 3.40 8.30 3.45 9.06 3.56 9.57 3.63
43 6.84 3.24 7.31 3.24 7.77 3.24 8.01 3.24 8.66 3.24 9.09 3.24
46 6.49 2.96 6.90 2.96 7.32 2.96 7.51 2.96 8.10 2.96 8.51 2.96
2.5+2.5+7.1 22 8.31 2.30 8.83 2.56 9.34 2.60 9.59 2.62 10.36 2.67 10.87 2.69
25 8.00 2.71 8.51 2.76 9.03 2.80 9.28 2.82 10.05 2.88 10.56 2.91
32 7.57 3.00 8.08 3.07 8.59 3.14 8.85 3.17 9.61 3.25 10.12 3.31
35 7.38 3.13 7.89 3.22 8.40 3.30
8.66 3.34 9.43 3.43 9.94 3.49
40 7.07 3.38 7.58 3.49 8.09 3.59 8.35 3.63 9.12 3.76 9.63 3.82
43 6.82 3.24 7.31 3.24 7.76 3.24 7.97 3.24 8.63 3.24 9.07 3.24
46 6.42 2.96 6.82 2.96 7.21 2.96 7.40 2.96 7.97 2.96 8.35 2.96
