Capacity Tables ED12-321A
120 SUPER MULTI NX B-Series Heat Pump
3D042743#1
3D042743#2
3D042743#3
3D042743#4
[Heating Capacity 240V 50Hz]
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+2.5+2.5+5.0 22 8.74 2.22 9.27 2.47 9.81 2.51 10.08 2.52 10.89 2.57 11.42 2.60
25 8.41 2.61 8.95 2.66 9.48 2.70 9.75 2.72 10.56 2.78 11.10 2.81
32 7.95 2.89 8.49 2.96 9.03 3.02 9.30 3.06 10.10 3.13 10.64 3.19
35 7.76 3.02 8.29 3.10 8.83 3.18
9.10 3.22 9.91 3.31 10.44 3.36
40 7.43 3.26 7.97 3.36 8.50 3.46 8.77 3.50 9.58 3.62 10.12 3.69
43 7.23 3.43 7.77 3.52 8.29 3.54 8.55 3.54 9.29 3.54 9.77 3.54
46 6.97 3.23 7.45 3.23 7.91 3.23 8.13 3.23 8.81 3.23 9.24 3.23
2.5+2.5+2.5+6.0 22 8.82 2.25 9.37 2.51 9.91 2.55 10.18 2.56 10.99 2.61 11.54 2.64
25 8.49 2.65 9.04 2.70 9.58 2.74 9.85 2.76 10.66 2.82 11.21 2.85
32 8.03 2.93 8.57 3.01 9.12 3.07 9.39 3.10 10.20 3.18 10.74 3.24
35 7.83 3.07 8.38 3.15 8.92 3.23
9.19 3.27 10.00 3.36 10.55 3.42
40 7.50 3.31 8.05 3.42 8.59 3.51 8.86 3.56 9.67 3.68 10.22 3.74
43 7.31 3.48 7.85 3.54 8.37 3.54 8.62 3.54 9.37 3.54 9.85 3.54
46 7.02 3.23 7.49 3.23 7.95 3.23 8.17 3.23 8.84 3.23 9.29 3.23
2.5+2.5+3.5+3.5 22 8.54 2.32 9.07 2.58 9.60 2.63 9.86 2.64 10.65 2.69 11.17 2.72
25 8.23 2.73 8.75 2.79 9.28 2.83 9.54 2.85 10.33 2.91 10.85 2.94
32 7.78 3.02 8.30 3.10 8.83 3.17 9.09 3.20 9.88 3.28 10.41 3.34
35 7.59 3.16 8.11 3.25 8.64 3.33
8.90 3.37 9.69 3.46 10.21 3.52
40 7.27 3.41 7.79 3.52 8.32 3.62 8.58 3.66 9.37 3.79 9.89 3.86
43 7.08 3.54 7.59 3.54 8.09 3.54 8.34 3.54 9.06 3.54 9.54 3.54
46 6.75 3.23 7.19 3.23 7.62 3.23 7.84 3.23 8.47 3.23 8.89 3.23
2.5+2.5+3.5+5.0 22 8.82 2.27 9.37 2.52 9.91 2.56 10.18 2.58 10.99 2.63 11.54 2.65
25 8.49 2.67 9.04 2.72 9.58 2.76 9.85 2.78 10.66 2.84 11.21 2.87
32 8.03 2.95 8.57 3.03 9.12 3.09 9.39 3.12 10.20 3.20 10.74 3.26
35 7.83 3.09 8.38 3.17 8.92 3.25
9.19 3.29 10.00 3.38 10.55 3.44
40 7.50 3.33 8.05 3.44 8.59 3.53 8.86 3.58 9.67 3.70 10.22 3.77
43 7.31 3.50 7.85 3.54 8.37 3.54 8.62 3.54 9.37 3.54 9.85 3.54
46 7.01 3.23 7.48 3.23 7.94 3.23 8.15 3.23 8.82 3.23 9.26 3.23
2.5+3.5+3.5+3.5 22 8.77 2.38 9.31 2.65 9.85 2.70 10.12 2.71 10.93 2.76 11.47 2.79
25 8.45 2.81 8.99 2.86 9.53 2.90 9.80 2.92 10.61 2.98 11.14 3.02
32 7.99 3.10 8.53 3.18 9.07 3.25 9.34 3.28 10.15 3.37 10.69 3.43
35 7.79 3.25 8.33 3.33 8.87 3.42
9.14 3.46 9.95 3.55 10.49 3.61
40 7.46 3.50 8.00 3.61 8.54 3.72 8.81 3.76 9.62 3.89 10.16 3.96
43 7.26 3.54 7.78 3.54 8.28 3.54 8.53 3.54 9.24 3.54 9.73 3.54
46 6.89 3.23 7.33 3.23 7.76 3.23 7.97 3.23 8.60 3.23 9.03 3.23
Symbols NOTES:
TC : Total capacity (kW) Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
PI : Power input (kW)
Combination
(Capacity)
Indoor
Air Temp.
°CDB
Outdoor Air Temp.:°CWB
-15 -10 -5 0 6 10 15
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
2.5 16 2.79 1.47 3.27 1.58 3.80 1.70 4.26 1.78 4.85 1.89 5.03 1.81 5.03 1.62
18 2.78 1.52 3.26 1.63 3.78 1.74 4.24 1.82 4.83 1.94 5.01 1.87 5.01 1.66
20 2.77 1.57 3.25 1.68 3.77 1.78 4.23 1.87
4.81 1.99 4.99 1.91 4.99 1.71
21 2.76 1.59 3.25 1.70 3.77 1.81 4.22 1.90 4.80 2.02 4.98 1.94 4.98 1.73
22 2.76 1.61 3.24 1.72 3.76 1.83 4.21 1.93 4.66 1.95 4.66 1.76 4.66 1.58
24 2.75 1.66 3.23 1.77 3.75 1.89 4.02 1.84 4.02 1.58 4.02 1.44 4.02 1.30
3.5 16 2.90 1.56 3.40 1.68 3.95 1.80 4.43 1.89 5.05 2.00 5.48 2.08 6.04 2.19
18 2.89 1.61 3.39 1.73 3.93 1.84 4.41 1.93 5.02 2.05 5.45 2.14 5.81 2.11
20 2.88 1.66 3.38 1.78 3.92 1.89 4.39 1.99
5.00 2.11 5.43 2.20 5.49 1.98
21 2.87 1.69 3.37 1.80 3.92 1.92 4.39 2.01 4.99 2.14 5.34 2.18 5.34 1.92
22 2.87 1.71 3.37 1.83 3.91 1.94 4.38 2.04 4.98 2.17 5.19 2.10 5.19 1.87
24 2.86 1.76 3.36 1.88 3.90 2.00 4.36 2.10 4.88 2.16 4.88 1.95 4.88 1.74
