ED12-321A Capacity Tables
SUPER MULTI NX B-Series Heat Pump 119
3
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+3.5+7.1 22 8.38 2.34 8.90 2.61 9.41 2.65 9.67 2.67 10.44 2.72 10.96 2.74
25 8.07 2.76 8.58 2.81 9.10 2.85 9.36 2.87 10.13 2.93 10.64 2.97
32 7.63 3.05 8.14 3.13 8.66 3.19 8.92 3.23 9.69 3.31 10.21 3.37
35 7.44 3.19 7.96 3.27 8.47 3.36
8.73 3.40 9.50 3.49 10.02 3.55
40 7.13 3.44 7.64 3.55 8.16 3.65 8.42 3.70 9.19 3.82 9.71 3.89
43 6.94 3.54 7.44 3.54 7.92 3.54 8.16 3.54 8.87 3.54 9.34 3.54
46 6.60 3.23 7.04 3.23 7.45 3.23 7.66 3.23 8.27 3.23 8.69 3.23
2.5+5.0+5.0 22 8.32 2.22 8.84 2.47 9.35 2.51 9.60 2.52 10.37 2.57 10.88 2.60
25 8.01 2.61 8.52 2.66 9.04 2.70 9.29 2.72 10.06 2.78 10.57 2.81
32 7.58 2.89 8.09 2.96 8.60 3.02 8.86 3.06 9.62 3.13 10.14 3.19
35 7.39 3.02 7.90 3.10 8.41 3.18
8.67 3.22 9.44 3.31 9.95 3.36
40 7.08 3.26 7.59 3.36 8.10 3.46 8.36 3.50 9.13 3.62 9.64 3.69
43 6.89 3.43 7.40 3.52 7.91 3.54 8.16 3.54 8.88 3.54 9.34 3.54
46 6.64 3.23 7.09 3.23 7.53 3.23 7.75 3.23 8.38 3.23 8.81 3.23
2.5+5.0+6.0 22 8.50 2.22 9.02 2.47 9.54 2.51 9.80 2.52 10.59 2.57 11.11 2.60
25 8.18 2.61 8.70 2.66 9.22 2.70 9.49 2.72 10.27 2.78 10.79 2.81
32 7.73 2.89 8.26 2.96 8.78 3.02 9.04 3.06 9.82 3.13 10.35 3.19
35 7.54 3.02 8.07 3.10 8.59 3.18
8.85 3.22 9.63 3.31 10.16 3.36
40 7.23 3.26 7.75 3.36 8.27 3.46 8.53 3.50 9.32 3.62 9.84 3.69
43 7.04 3.43 7.56 3.52 8.07 3.54 8.32 3.54 9.06 3.54 9.52 3.54
46 6.78 3.23 7.24 3.23 7.69 3.23 7.90 3.23 8.57 3.23 9.00 3.23
3.5+3.5+3.5 22 7.89 2.22 8.38 2.48 8.86 2.52 9.10 2.53 9.83 2.58 10.32 2.60
25 7.60 2.62 8.08 2.67 8.57 2.71 8.81 2.73 9.54 2.79 10.02 2.82
32 7.18 2.90 7.67 2.97 8.15 3.03 8.40 3.06 9.12 3.14 9.61 3.20
35 7.01 3.03 7.49 3.11 7.98 3.19
8.22 3.23 8.95 3.32 9.43 3.37
40 6.71 3.27 7.20 3.37 7.68 3.47 7.93 3.51 8.65 3.63 9.14 3.70
43 6.53 3.44 7.02 3.53 7.50 3.54 7.74 3.54 8.43 3.54 8.88 3.54
46 6.29 3.23 6.71 3.23 7.14 3.23 7.34 3.23 7.94 3.23 8.34 3.23
3.5+3.5+5.0 22 8.29 2.23 8.80 2.48 9.31 2.52 9.57 2.54 10.34 2.59 10.85 2.61
25 7.98 2.63 8.49 2.68 9.00 2.72 9.26 2.74 10.03 2.79 10.54 2.83
32 7.55 2.91 8.06 2.98 8.57 3.04 8.83 3.07 9.59 3.15 10.10 3.21
35 7.36 3.04 7.87 3.12 8.38 3.20
8.64 3.24 9.41 3.33 9.92 3.38
40 7.05 3.28 7.56 3.38 8.07 3.48 8.33 3.52 9.10 3.64 9.61 3.71
43 6.87 3.45 7.38 3.54 7.88 3.54 8.12 3.54 8.85 3.54 9.31 3.54
46 6.61 3.23 7.05 3.23 7.49 3.23 7.71 3.23 8.33 3.23 8.76 3.23
3.5+3.5+6.0 22 8.47 2.23 8.99 2.48 9.51 2.52 9.77 2.54 10.55 2.59 11.07 2.61
25 8.15 2.63 8.67 2.68 9.19 2.72 9.45 2.74 10.23 2.79 10.75 2.83
32 7.71 2.91 8.23 2.98 8.75 3.04 9.01 3.07 9.79 3.15 10.31 3.21
35 7.52 3.04 8.04 3.12 8.56 3.20
8.82 3.24 9.60 3.33 10.12 3.38
40 7.20 3.28 7.72 3.38 8.24 3.48 8.50 3.52 9.28 3.64 9.81 3.71
43 7.01 3.45 7.53 3.54 8.04 3.54 8.29 3.54 9.02 3.54 9.49 3.54
46 6.74 3.23 7.20 3.23 7.65 3.23 7.86 3.23 8.51 3.23 8.95 3.23
3.5+5.0+5.0 22 8.74 2.27 9.27 2.52 9.81 2.56 10.08 2.58 10.89 2.63 11.42 2.65
25 8.41 2.67 8.95 2.72 9.48 2.76 9.75 2.78 10.56 2.84 11.10 2.87
32 7.95 2.95 8.49 3.03 9.03 3.09 9.30 3.12 10.10 3.20 10.64 3.26
35 7.76 3.09 8.29 3.17 8.83 3.25
9.10 3.29 9.91 3.38 10.44 3.44
40 7.43 3.33 7.97 3.44 8.50 3.53 8.77 3.58 9.58 3.70 10.12 3.77
43 7.23 3.50 7.77 3.54 8.29 3.54 8.54 3.54 9.28 3.54 9.76 3.54
46 6.94 3.23 7.41 3.23 7.86 3.23 8.08 3.23 8.74 3.23 9.17 3.23
2.5+2.5+2.5+2.5 22 8.07 2.00 8.57 2.23 9.07 2.27 9.32 2.28 10.06 2.32 10.56 2.35
25 7.77 2.36 8.27 2.41 8.77 2.44 9.01 2.46 9.76 2.51 10.25 2.54
32 7.35 2.61 7.85 2.68 8.34 2.73 8.59 2.76 9.34 2.83 9.83 2.89
35 7.17 2.73 7.67 2.80 8.16 2.88
8.41 2.91 9.15 2.99 9.65 3.04
40 6.87 2.94 7.36 3.04 7.86 3.13 8.11 3.16 8.85 3.27 9.35 3.33
43 6.69 3.10 7.18 3.18 7.68 3.28 7.93 3.33 8.67 3.45 9.17 3.52
46 6.50 3.23 6.98 3.23 7.45 3.23 7.67 3.23 8.32 3.23 8.75 3.23
2.5+2.5+2.5+3.5 22 8.27 2.12 8.77 2.36 9.28 2.40 9.54 2.41 10.30 2.46 10.81 2.48
25 7.96 2.50 8.47 2.55 8.97 2.59 9.23 2.60 9.99 2.66 10.50 2.69
32 7.52 2.76 8.03 2.83 8.54 2.89 8.80 2.92 9.56 3.00 10.07 3.06
35 7.34 2.89 7.85 2.97 8.36 3.04
8.61 3.08 9.37 3.16 9.88 3.22
40 7.03 3.12 7.54 3.22 8.05 3.31 8.30 3.35 9.06 3.46 9.57 3.53
43 6.85 3.28 7.35 3.37 7.86 3.47 8.12 3.52 8.85 3.54 9.32 3.54
46 6.64 3.23 7.11 3.23 7.57 3.23 7.78 3.23 8.44 3.23 8.88 3.23
