ED12-321A Capacity Tables
SUPER MULTI NX B-Series Heat Pump 103
3
3D042742#1
3D042742#2
[Heating Capacity 240V 50Hz]
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+3.5+5.0 22 7.111.807.552.007.992.038.212.058.862.089.302.10
25 6.85 2.12 7.29 2.16 7.72 2.19 7.94 2.20 8.60 2.25 9.04 2.28
32 6.48 2.34 6.91 2.40 7.35 2.45 7.57 2.48 8.23 2.54 8.66 2.59
35 6.32 2.45 6.75 2.51 7.19 2.58
7.41 2.61 8.07 2.68 8.50 2.73
40 6.05 2.64 6.49 2.73 6.93 2.80 7.14 2.84 7.80 2.93 8.24 2.99
43 5.89 2.78 6.33 2.86 6.77 2.94 6.98 2.98 7.64 3.09 8.08 3.15
46 5.73 2.91 6.17 3.02 6.61 3.11 6.83 3.17 7.47 3.27 7.88 3.27
3.5+3.5+3.5 22 7.091.917.522.137.962.178.172.188.832.229.262.24
25 6.82 2.25 7.26 2.30 7.69 2.33 7.91 2.35 8.56 2.40 9.00 2.42
32 6.45 2.49 6.89 2.56 7.32 2.61 7.54 2.64 8.19 2.71 8.63 2.76
35 6.29 2.61 6.73 2.68 7.16 2.75
7.38 2.78 8.03 2.86 8.47 2.90
40 6.03 2.81 6.46 2.90 6.90 2.99 7.12 3.02 7.77 3.13 8.20 3.18
43 5.87 2.96 6.30 3.04 6.74 3.13 6.96 3.18 7.61 3.29 8.05 3.36
46 5.71 3.10 6.14 3.21 6.58 3.27 6.79 3.27 7.41 3.27 7.81 3.27
Symbols NOTE:
TC : Total capacity (kW) Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
PI : Power input (kW)
Combination
(Capacity)
Indoor
Air Temp.
°CDB
Outdoor Air Temp.:°CWB
-15 -10 -5 0 6 10 15
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
2.5 16 2.76 1.28 3.23 1.37 3.75 1.47 4.21 1.55 4.79 1.64 5.03 1.62 5.03 1.45
18 2.74 1.32 3.22 1.42 3.74 1.51 4.19 1.59 4.77 1.68 5.01 1.66 5.01 1.49
20 2.73 1.36 3.21 1.46 3.73 1.55 4.17 1.63
4.75 1.73 4.99 1.71 4.99 1.53
21 2.73 1.38 3.21 1.48 3.72 1.57 4.17 1.65 4.74 1.75 4.98 1.73 4.98 1.55
22 2.72 1.40 3.20 1.50 3.72 1.59 4.16 1.67 4.66 1.74 4.66 1.59 4.66 1.43
24 2.71 1.44 3.19 1.54 3.71 1.64 4.02 1.63 4.02 1.42 4.02 1.30 4.02 1.18
3.5 16 3.13 1.58 3.67 1.69 4.26 1.82 4.78 1.90 5.45 2.02 5.92 2.10 6.11 1.97
18 3.12 1.63 3.66 1.74 4.25 1.86 4.76 1.95 5.42 2.07 5.81 2.11 5.81 1.87
20 3.11 1.68 3.65 1.79 4.24 1.91 4.75 2.00
5.40 2.13 5.49 1.97 5.49 1.75
21 3.10 1.70 3.64 1.82 4.23 1.94 4.74 2.03 5.34 2.12 5.34 1.91 5.34 1.70
22 3.10 1.73 3.64 1.84 4.23 1.96 4.73 2.06 5.19 2.05 5.19 1.85 5.19 1.65
24 3.08 1.78 3.63 1.90 4.21 2.02 4.71 2.12 4.88 1.92 4.88 1.72 4.88 1.54
5.0 16 4.29 2.09 5.03 2.24 5.84 2.40 6.55 2.52 7.47 2.67 8.11 2.78 8.94 2.93
18 4.28 2.15 5.02 2.31 5.82 2.46 6.53 2.58 7.43 2.74 8.07 2.86 8.89 3.01
20 4.26 2.22 5.00 2.38 5.81 2.53 6.50 2.65
7.40 2.82 8.03 2.94 8.85 3.10
21 4.25 2.25 4.99 2.41 5.80 2.56 6.49 2.69 7.38 2.86 8.01 2.98 8.83 3.14
22 4.24 2.29 4.99 2.44 5.79 2.60 6.48 2.73 7.37 2.90 7.99 3.02 8.81 3.19
24 4.23 2.36 4.97 2.51 5.78 2.67 6.46 2.81 7.34 2.99 7.96 3.11 8.34 2.95
6.0 16 4.84 2.46 5.68 2.64 6.59 2.83 7.40 2.97 8.43 3.15 9.15 3.28 10.08 3.45
18 4.82 2.54 5.66 2.72 6.57 2.90 7.37 3.04 8.39 3.23 9.10 3.37 10.03 3.55
20 4.81 2.61 5.64 2.80 6.55 2.98 7.34 3.12
8.35 3.32 9.06 3.46 9.98 3.65
21 4.80 2.65 5.64 2.84 6.54 3.02 7.32 3.17 8.33 3.37 9.04 3.51 9.96 3.70
22 4.79 2.69 5.63 2.88 6.53 3.06 7.31 3.21 8.31 3.42 9.02 3.56 9.94 3.76
24 4.77 2.77 5.61 2.95 6.52 3.15 7.29 3.31 8.28 3.52 8.98 3.67 9.40 3.43
2.5+2.5 16 4.61 2.24 5.41 2.41 6.28 2.58 7.04 2.71 8.02 2.87 8.71 2.99 9.60 3.15
18 4.59 2.31 5.39 2.48 6.26 2.65 7.01 2.78 7.99 2.95 8.67 3.07 9.55 3.24
20 4.58 2.39 5.37 2.55 6.24 2.72 6.99 2.85
9.40 3.44 8.63 3.16 9.45 3.28
21 4.57 2.42 5.37 2.59 6.23 2.75 6.97 2.89 7.93 3.07 8.61 3.20 9.40 3.32
22 4.56 2.46 5.36 2.62 6.22 2.79 6.96 2.93 7.92 3.12 8.55 3.22 8.55 2.75
24 4.54 2.53 5.34 2.70 6.20 2.87 6.94 3.02 7.88 3.21 8.04 2.93 8.04 2.51
2.5+3.5 16 4.87 2.46 5.72 2.65 6.63 2.84 7.44 2.98 8.48 3.16 9.20 3.29 10.14 3.46
18 4.85 2.54 5.70 2.73 6.61 2.91 7.41 3.05 9.62 3.38 9.16 3.38 9.70 3.25
20 4.84 2.62 5.68 2.80 6.59 2.98 7.38 3.13
9.58 3.47 9.11 3.47 9.60 3.30
21 4.83 2.66 5.67 2.84 6.58 3.03 7.37 3.18 8.38 3.38 9.09 3.52 9.55 3.31
22 4.82 2.70 5.66 2.88 6.57 3.07 7.36 3.22 8.36 3.43 8.70 3.24 8.70 2.76
24 4.80 2.78 5.64 2.96 6.56 3.16 7.33 3.32 8.19 3.39 8.19 2.95 8.19 2.53
