Capacity Tables ED12-321A
52 SUPER MULTI NX B-Series Cooling Only
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+6.0 22 7.77 2.16 8.24 2.41 8.72 2.45 8.96 2.46 9.68 2.51 10.15 2.53
25 7.48 2.55 7.95 2.60 8.43 2.64 8.67 2.65 9.39 2.71 9.86 2.74
32 7.07 2.82 7.55 2.89 8.03 2.95 8.26 2.98 8.98 3.06 9.46 3.11
35 6.90 2.95 7.37 3.02 7.85 3.10
8.09 3.14 8.81 3.23 9.28 3.28
40 6.61 3.18 7.08 3.28 7.56 3.37 7.80 3.41 8.52 3.53 8.99 3.60
43 6.43 3.34 6.91 3.44 7.39 3.54 7.63 3.57 8.32 3.57 8.78 3.57
46 6.13 2.99 6.53 2.99 6.91 2.99 7.10 2.99 7.68 2.99 8.07 2.99
2.5+7.1 22 7.99 2.40 8.48 2.67 8.97 2.71 9.22 2.73 9.95 2.78 10.44 2.80
25 7.69 2.82 8.18 2.88 8.67 2.92 8.92 2.94 9.65 3.00 10.14 3.04
32 7.27 3.12 7.76 3.20 8.25 3.27 8.50 3.30 9.24 3.39 9.73 3.45
35 7.09 3.27 7.58 3.35 8.07 3.44
8.32 3.48 9.06 3.58 9.55 3.63
40 6.79 3.52 7.28 3.64 7.78 3.74 8.02 3.78 8.76 3.91 9.25 3.98
43 6.60 3.57 7.08 3.57 7.54 3.57 7.76 3.57 8.43 3.57 8.87 3.57
46 6.10 2.99 6.48 2.99 6.84 2.99 7.01 2.99 7.55 2.99 7.91 2.99
3.5+3.5 22 6.291.687.462.288.012.398.232.418.892.459.332.47
25 6.29 2.09 7.31 2.54 7.74 2.58 7.96 2.59 8.62 2.65 9.06 2.68
32 6.29 2.57 6.93 2.82 7.37 2.88 7.59 2.91 8.25 2.99 8.69 3.05
35 6.29 2.84 6.77 2.96 7.21 3.03
7.43 3.07 8.09 3.15 8.53 3.21
40 6.07 3.11 6.51 3.21 6.94 3.30 7.16 3.34 7.82 3.45 8.26 3.52
43 5.91 3.27 6.35 3.36 6.78 3.46 7.00 3.51 7.66 3.57 8.09 3.57
46 5.66 2.99 6.04 2.99 6.40 2.99 6.58 2.99 7.11 2.99 7.47 2.99
3.5+5.0 22 7.76 2.27 8.23 2.53 8.71 2.57 8.95 2.59 9.67 2.64 10.14 2.66
25 7.47 2.68 7.94 2.73 8.42 2.77 8.66 2.79 9.38 2.85 9.85 2.88
32 7.06 2.96 7.54 3.04 8.02 3.10 8.25 3.13 8.97 3.21 9.45 3.27
35 6.89 3.10 7.36 3.18 7.84 3.26
8.08 3.30 8.80 3.39 9.27 3.45
40 6.60 3.34 7.07 3.45 7.55 3.54 7.79 3.59 8.51 3.71 8.98 3.78
43 6.42 3.51 6.90 3.57 7.37 3.57 7.60 3.57 8.27 3.57 8.71 3.57
46 6.04 2.99 6.41 2.99 6.78 2.99 6.97 2.99 7.51 2.99 7.87 2.99
3.5+6.0 22 7.97 2.28 8.46 2.54 8.95 2.58 9.19 2.60 9.93 2.64 10.42 2.67
25 7.67 2.68 8.16 2.74 8.65 2.78 8.90 2.80 9.63 2.85 10.12 2.89
32 7.25 2.97 7.74 3.05 8.23 3.11 8.48 3.14 9.21 3.22 9.70 3.28
35 7.08 3.11 7.57 3.19 8.06 3.27
8.30 3.31 9.03 3.40 9.52 3.46
40 6.78 3.35 7.27 3.46 7.76 3.56 8.00 3.60 8.74 3.72 9.23 3.79
43 6.60 3.52 7.09 3.57 7.57 3.57 7.80 3.57 8.49 3.57 8.95 3.57
46 6.19 2.99 6.58 2.99 6.96 2.99 7.15 2.99 7.70 2.99 8.08 2.99
3.5+7.1 22 8.27 2.48 8.77 2.76 9.28 2.81 9.54 2.82 10.30 2.88 10.81 2.90
25 7.96 2.92 8.47 2.98 8.97 3.02 9.23 3.04 9.99 3.10 10.50 3.14
32 7.52 3.23 8.03 3.31 8.54 3.38 8.80 3.42 9.56 3.50 10.07 3.57
35 7.34 3.38 7.85 3.47 8.36 3.56
8.61 3.60 9.37 3.70 9.88 3.76
40 7.03 3.64 7.54 3.76 8.05 3.87 8.30 3.91 9.06 4.05 9.57 4.12
43 6.82 3.57 7.29 3.57 7.75 3.57 7.98 3.57 8.65 3.57 9.09 3.57
46 6.23 2.99 6.60 2.99 6.97 2.99 7.14 2.99 7.68 2.99 8.04 2.99
5.0+5.0 22 8.25 2.24 8.75 2.49 9.26 2.53 9.51 2.55 10.28 2.60 10.78 2.62
25 7.94 2.64 8.45 2.69 8.95 2.73 9.21 2.75 9.97 2.80 10.47 2.83
32 7.51 2.92 8.01 2.99 8.52 3.05 8.77 3.08 9.54 3.16 10.04 3.22
35 7.32 3.05 7.83 3.13 8.34 3.21
8.59 3.25 9.35 3.34 9.86 3.39
40 7.01 3.29 7.52 3.39 8.03 3.49 8.28 3.53 9.04 3.65 9.55 3.72
43 6.83 3.46 7.34 3.56 7.84 3.57 8.09 3.57 8.81 3.57 9.27 3.57
46 6.44 2.99 6.85 2.99 7.26 2.99 7.45 2.99 8.03 2.99 8.44 2.99
5.0+6.0 22 8.34 2.23 8.86 2.48 9.37 2.52 9.63 2.54 10.39 2.59 10.91 2.61
25 8.03 2.63 8.54 2.68 9.06 2.72 9.31 2.74 10.08 2.79 10.60 2.83
32 7.59 2.91 8.11 2.98 8.62 3.04 8.88 3.07 9.65 3.15 10.16 3.21
35 7.41 3.04 7.92 3.12 8.43 3.20
8.69 3.24 9.46 3.33 9.97 3.38
40 7.10 3.28 7.61 3.38 8.12 3.48 8.38 3.52 9.15 3.64 9.66 3.71
43 6.91 3.45 7.42 3.55 7.93 3.57 8.18 3.57 8.91 3.57 9.37 3.57
46 6.52 2.99 6.93 2.99 7.35 2.99 7.54 2.99 8.14 2.99 8.55 2.99
