Capacity Tables ED12-321A
54 SUPER MULTI NX B-Series Cooling Only
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+2.5+7.1 22 8.59 2.30 9.12 2.56 9.65 2.60 9.91 2.62 10.71 2.67 11.23 2.69
25 8.27 2.71 8.80 2.76 9.33 2.80 9.59 2.82 10.38 2.88 10.91 2.91
32 7.82 3.00 8.35 3.07 8.88 3.14 9.14 3.17 9.94 3.25 10.46 3.31
35 7.63 3.13 8.16 3.22 8.69 3.30
8.95 3.34 9.74 3.43 10.27 3.49
40 7.31 3.38 7.84 3.49 8.36 3.59 8.63 3.63 9.42 3.76 9.95 3.82
43 7.12 3.56 7.64 3.57 8.15 3.57 8.40 3.57 9.14 3.57 9.63 3.57
46 6.65 2.99 7.07 2.99 7.49 2.99 7.68 2.99 8.28 2.99 8.67 2.99
2.5+3.5+3.5 22 7.96 2.16 8.45 2.40 8.94 2.44 9.18 2.45 9.92 2.50 10.41 2.52
25 7.66 2.54 8.15 2.59 8.64 2.63 8.88 2.64 9.62 2.70 10.11 2.73
32 7.24 2.81 7.73 2.88 8.22 2.94 8.47 2.97 9.20 3.05 9.69 3.10
35 7.07 2.94 7.56 3.01 8.05 3.09
8.29 3.13 9.02 3.22 9.51 3.27
40 6.77 3.17 7.26 3.27 7.75 3.36 7.99 3.40 8.73 3.52 9.22 3.58
43 6.59 3.33 7.08 3.42 7.57 3.53 7.81 3.57 8.53 3.57 8.99 3.57
46 6.28 2.99 6.69 2.99 7.10 2.99 7.29 2.99 7.88 2.99 8.27 2.99
2.5+3.5+5.0 22 8.53 2.18 9.06 2.43 9.58 2.47 9.85 2.49 10.63 2.53 11.16 2.55
25 8.22 2.57 8.74 2.62 9.27 2.66 9.53 2.68 10.32 2.73 10.84 2.76
32 7.77 2.84 8.29 2.92 8.82 2.98 9.08 3.01 9.87 3.09 10.39 3.14
35 7.58 2.98 8.10 3.05 8.63 3.13
8.89 3.17 9.68 3.26 10.20 3.31
40 7.26 3.21 7.78 3.31 8.31 3.40 8.57 3.45 9.36 3.56 9.88 3.63
43 7.07 3.38 7.59 3.47 8.12 3.57 8.37 3.57 9.11 3.57 9.59 3.57
46 6.72 2.99 7.15 2.99 7.58 2.99 7.79 2.99 8.41 2.99 8.82 2.99
2.5+3.5+6.0 22 8.57 2.18 9.10 2.43 9.63 2.47 9.89 2.49 10.68 2.53 11.21 2.55
25 8.25 2.57 8.78 2.62 9.31 2.66 9.57 2.68 10.36 2.73 10.89 2.76
32 7.80 2.84 8.33 2.92 8.86 2.98 9.12 3.01 9.91 3.09 10.44 3.14
35 7.61 2.98 8.14 3.05 8.67 3.13
8.93 3.17 9.72 3.26 10.25 3.31
40 7.29 3.21 7.82 3.31 8.35 3.40 8.61 3.45 9.40 3.56 9.93 3.63
43 7.10 3.38 7.63 3.47 8.15 3.57 8.41 3.57 9.15 3.57 9.63 3.57
46 6.75 2.99 7.17 2.99 7.61 2.99 7.83 2.99 8.44 2.99 8.86 2.99
2.5+3.5+7.1 22 8.67 2.35 9.20 2.61 9.74 2.66 10.00 2.67 10.80 2.72 11.33 2.75
25 8.35 2.77 8.88 2.82 9.41 2.86 9.68 2.88 10.48 2.94 11.01 2.97
32 7.89 3.06 8.42 3.14 8.96 3.20 9.22 3.24 10.02 3.32 10.56 3.38
35 7.70 3.20 8.23 3.28 8.76 3.37
9.03 3.41 9.83 3.50 10.36 3.56
40 7.37 3.45 7.91 3.56 8.44 3.66 8.71 3.71 9.51 3.83 10.04 3.90
43 7.18 3.57 7.70 3.57 8.21 3.57 8.45 3.57 9.18 3.57 9.66 3.57
46 6.66 2.99 7.08 2.99 7.48 2.99 7.68 2.99 8.27 2.99 8.67 2.99
2.5+5.0+5.0 22 8.60 2.20 9.13 2.45 9.66 2.49 9.92 2.50 10.72 2.55 11.25 2.57
25 8.28 2.59 8.81 2.64 9.34 2.68 9.60 2.69 10.40 2.75 10.93 2.78
32 7.83 2.86 8.36 2.94 8.89 3.00 9.15 3.03 9.95 3.11 10.48 3.16
35 7.64 2.99 8.17 3.07 8.70 3.15
8.96 3.19 9.75 3.28 10.28 3.33
40 7.32 3.23 7.85 3.33 8.37 3.43 8.64 3.47 9.43 3.59 9.96 3.65
43 7.12 3.40 7.65 3.49 8.18 3.57 8.44 3.57 9.18 3.57 9.66 3.57
46 6.76 2.99 7.19 2.99 7.62 2.99 7.82 2.99 8.46 2.99 8.87 2.99
2.5+5.0+6.0 22 8.77 2.22 9.31 2.47 9.85 2.51 10.12 2.52 10.93 2.57 11.47 2.60
25 8.45 2.61 8.99 2.66 9.53 2.70 9.80 2.72 10.61 2.78 11.14 2.81
32 7.99 2.89 8.53 2.96 9.07 3.02 9.34 3.06 10.15 3.13 10.69 3.19
35 7.79 3.02 8.33 3.10 8.87 3.18
9.14 3.22 9.95 3.31 10.49 3.36
40 7.46 3.26 8.00 3.36 8.54 3.46 8.81 3.50 9.62 3.62 10.16 3.69
43 7.27 3.43 7.81 3.52 8.34 3.57 8.60 3.57 9.34 3.57 9.82 3.57
46 6.87 2.99 7.32 2.99 7.75 2.99 7.95 2.99 8.59 2.99 9.01 2.99
2.5+5.0+7.1 22 8.98 2.11 9.53 2.35 10.08 2.38 10.36 2.40 11.18 2.44 11.74 2.47
25 8.64 2.48 9.19 2.53 9.74 2.57 10.02 2.59 10.85 2.64 11.40 2.67
32 8.17 2.75 8.72 2.82 9.28 2.87 9.55 2.90 10.38 2.98 10.93 3.04
35 7.97 2.87 8.52 2.95 9.07 3.02
9.35 3.06 10.18 3.14 10.73 3.20
40 7.63 3.10 8.19 3.20 8.74 3.29 9.01 3.33 9.84 3.44 10.39 3.50
43 7.43 3.26 7.99 3.35 8.54 3.45 8.81 3.50 9.61 3.57 10.11 3.57
46 7.09 2.99 7.56 2.99 8.01 2.99 8.23 2.99 8.87 2.99 9.28 2.99
