ED12-321A Capacity Tables
SUPER MULTI NX B-Series Heat Pump 117
3
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+7.1 22 7.72 2.39 8.19 2.66 8.67 2.70 8.91 2.72 9.62 2.77 10.09 2.80
25 7.43 2.81 7.90 2.87 8.38 2.91 8.62 2.93 9.33 2.99 9.80 3.03
32 7.03 3.11 7.50 3.19 7.98 3.26 8.21 3.29 8.93 3.38 9.40 3.44
35 6.85 3.26 7.33 3.34 7.80 3.43
8.04 3.47 8.75 3.57 9.23 3.62
40 6.56 3.51 7.04 3.62 7.51 3.73 7.75 3.77 8.46 3.90 8.94 3.97
43 6.38 3.54 6.84 3.54 7.27 3.54 7.49 3.54 8.13 3.54 8.56 3.54
46 6.05 3.23 6.44 3.23 6.82 3.23 7.01 3.23 7.56 3.23 7.93 3.23
3.5+3.5 22 6.291.787.332.357.752.387.962.408.602.449.032.47
25 6.29 2.22 7.07 2.53 7.49 2.57 7.71 2.59 8.34 2.64 8.77 2.67
32 6.28 2.75 6.71 2.82 7.13 2.87 7.34 2.90 7.98 2.98 8.41 3.04
35 6.13 2.87 6.55 2.95 6.98 3.02
7.19 3.06 7.83 3.14 8.25 3.20
40 5.87 3.10 6.30 3.20 6.72 3.29 6.93 3.33 7.57 3.44 7.99 3.50
43 5.72 3.26 6.14 3.35 6.57 3.45 6.78 3.50 7.41 3.54 7.83 3.54
46 5.54 3.23 5.94 3.23 6.33 3.23 6.51 3.23 7.07 3.23 7.43 3.23
3.5+5.0 22 7.512.277.972.538.432.578.662.599.352.649.822.66
25 7.23 2.68 7.69 2.73 8.15 2.77 8.38 2.79 9.07 2.85 9.54 2.88
32 6.83 2.96 7.30 3.04 7.76 3.10 7.99 3.13 8.68 3.21 9.14 3.27
35 6.67 3.10 7.13 3.18 7.59 3.26
7.82 3.30 8.51 3.39 8.97 3.45
40 6.39 3.34 6.85 3.45 7.31 3.54 7.54 3.59 8.23 3.71 8.69 3.78
43 6.22 3.51 6.68 3.54 7.12 3.54 7.34 3.54 7.99 3.54 8.42 3.54
46 5.96 3.23 6.35 3.23 6.74 3.23 6.93 3.23 7.51 3.23 7.88 3.23
3.5+6.0 22 7.70 2.28 8.17 2.54 8.65 2.58 8.88 2.60 9.59 2.64 10.07 2.67
25 7.41 2.68 7.89 2.74 8.36 2.78 8.60 2.80 9.31 2.85 9.78 2.89
32 7.01 2.97 7.48 3.05 7.96 3.11 8.19 3.14 8.90 3.22 9.38 3.28
35 6.84 3.11 7.31 3.19 7.78 3.27
8.02 3.31 8.73 3.40 9.20 3.46
40 6.55 3.35 7.02 3.46 7.50 3.56 7.73 3.60 8.44 3.72 8.92 3.79
43 6.38 3.52 6.85 3.54 7.30 3.54 7.53 3.54 8.19 3.54 8.62 3.54
46 6.10 3.23 6.52 3.23 6.91 3.23 7.11 3.23 7.68 3.23 8.07 3.23
3.5+7.1 22 7.99 2.48 8.48 2.76 8.97 2.81 9.22 2.82 9.95 2.88 10.44 2.90
25 7.69 2.92 8.18 2.98 8.67 3.02 8.92 3.04 9.65 3.10 10.14 3.14
32 7.27 3.23 7.76 3.31 8.25 3.38 8.50 3.42 9.24 3.50 9.73 3.57
35 7.09 3.38 7.58 3.47 8.07 3.56
8.32 3.60 9.06 3.70 9.55 3.76
40 6.79 3.64 7.28 3.76 7.78 3.87 8.02 3.91 8.76 4.05 9.25 4.12
43 6.57 3.54 7.04 3.54 7.48 3.54 7.69 3.54 8.33 3.54 8.76 3.54
46 6.20 3.23 6.58 3.23 6.97 3.23 7.14 3.23 7.70 3.23 8.07 3.23
5.0+5.0 22 7.98 2.23 8.47 2.48 8.96 2.52 9.20 2.54 9.94 2.59 10.43 2.61
25 7.68 2.63 8.17 2.68 8.66 2.72 8.91 2.74 9.64 2.79 10.13 2.83
32 7.26 2.91 7.75 2.98 8.24 3.04 8.49 3.07 9.22 3.15 9.72 3.21
35 7.08 3.04 7.57 3.12 8.06 3.20
8.31 3.24 9.05 3.33 9.54 3.38
40 6.79 3.28 7.28 3.38 7.77 3.48 8.01 3.52 8.75 3.64 9.24 3.71
43 6.61 3.45 7.10 3.54 7.58 3.54 7.82 3.54 8.52 3.54 8.98 3.54
46 6.36 3.23 6.79 3.23 7.21 3.23 7.41 3.23 8.02 3.23 8.43 3.23
5.0+6.0 22 8.07 2.22 8.57 2.48 9.07 2.52 9.32 2.53 10.06 2.58 10.56 2.60
25 7.77 2.62 8.27 2.67 8.77 2.71 9.01 2.73 9.76 2.79 10.25 2.82
32 7.35 2.90 7.85 2.97 8.34 3.03 8.59 3.06 9.34 3.14 9.83 3.20
35 7.17 3.03 7.67 3.11 8.16 3.19
8.41 3.23 9.15 3.32 9.65 3.37
40 6.87 3.27 7.36 3.37 7.86 3.47 8.11 3.51 8.85 3.63 9.35 3.70
43 6.69 3.44 7.18 3.53 7.67 3.54 7.92 3.54 8.62 3.54 9.09 3.54
46 6.43 3.23 6.87 3.23 7.31 3.23 7.51 3.23 8.12 3.23 8.54 3.23
5.0+7.1 22 8.10 2.35 8.60 2.62 9.10 2.67 9.35 2.68 10.10 2.73 10.59 2.76
25 7.80 2.77 8.30 2.83 8.80 2.87 9.05 2.89 9.79 2.95 10.29 2.98
32 7.38 3.07 7.87 3.15 8.37 3.21 8.62 3.25 9.37 3.33 9.87 3.39
35 7.19 3.21 7.69 3.29 8.19 3.38
8.44 3.42 9.19 3.51 9.69 3.57
40 6.89 3.46 7.39 3.57 7.89 3.67 8.14 3.72 8.88 3.85 9.38 3.92
43 6.70 3.54 7.19 3.54 7.66 3.54 7.89 3.54 8.56 3.54 9.01 3.54
46 6.38 3.23 6.79 3.23 7.19 3.23 7.39 3.23 7.99 3.23 8.38 3.23
6.0+6.0 22 8.15 2.28 8.65 2.54 9.15 2.58 9.40 2.60 10.16 2.64 10.66 2.67
25 7.85 2.68 8.35 2.74 8.85 2.78 9.10 2.80 9.85 2.85 10.35 2.89
32 7.42 2.97 7.92 3.05 8.42 3.11 8.67 3.14 9.42 3.22 9.93 3.28
35 7.24 3.11 7.74 3.19 8.24 3.27
8.49 3.31 9.24 3.40 9.74 3.46
40 6.93 3.35 7.43 3.46 7.93 3.56 8.19 3.60 8.94 3.72 9.44 3.79
43 6.75 3.52 7.25 3.54 7.73 3.54 7.97 3.54 8.67 3.54 9.14 3.54
46 6.47 3.23 6.90 3.23 7.32 3.23 7.52 3.23 8.13 3.23 8.54 3.23
