Operations ED12-321A
212 Operation Manual
FLK(X) 25/35/50/60 A
Names of parts
■
Indoor Unit
The indoor unit can be installed either to the ceiling or to a wall. The descriptions contained in this manual show the
case when installation is being carried out to the ceiling. (The methods of operation used are the same when
installing to a wall.)
CAUTION
• Before opening the front grille, be sure to stop the operation and turn the breaker OFF.
O
N
O
F
F
