Asus RS300-E10-PS4 [117/164] Monitor menu

5-37

ASUS RS300-E10 Series

Fan Speed Control [Auto Mode]

Allowsyoutoselectthepower-onstatefortheNumLock.

Congurationoptions:[AutoMode][FullSpeedMode][ManualSpeedMode]

The following item appears only when you set the Fan Speed Control to [Manual Speed

Mode].

REAR_FAN1 / CPU_FAN1 / FRNT_FAN1-4 Duty [50]

Allows you to set the desired POST Report waiting time from 1 to 10 seconds. Use the

<+>or<->toadjustthevalue.Thevaluesrangefrom10to100.

5.8 Monitor menu

Thismenudisplaysthesystemtemperature,fanspeed,andpowerstatus.Youcanalso

change the fan settings in this menu.
