Asus RS300-E10-PS4 [17/164] Internal features

ASUS RS300-E10 Series

1-7

RS300-E10-RS4

1.6 Internal features

The barebone server includes the basic components as shown.

The barebone server does not include a oppy disk drive. Connect a USB oppy disk drive

to any of the USB ports on the front or rear panel if you need to use a oppy disk.

WARNING

HAZARDOUS MOVING PARTS

KEEP FINGERS AND OTHER BODY PARTS AWAY

1. 1+1 Redundant 450W 80

PLUS Gold Power Supply

2. PCI Express slot Riser

Card

3. ASUS P11C-C/4L/SYS

Server Board

4. System fans

5. SAS / SATA backplane

(hidden)

6. HDD tray 1-4

7. Front I/O boards (hidden)

8. Slim-type optical drive

9. SSD Cage

10. Asset Tag

Turn off the system power and detach the power supply before removing or replacing any

system component.
