Asus RS300-E10-PS4 [42/164] Sata sas backplane cabling

Chapter 2: Hardware Information

2-22

2.7 SATA/SAS backplane cabling

RS300-E10-PS4

RS300-E10-RS4

Connects the SATA/SAS HDDs

Connects the data cable

connected to the motherboard

Connects a 8-pin plug

from power supply
