ASUS RS300-E10 Series
1-5
Model Name RS300-E10-RS4 RS300-E10-PS4
Rear I/O Ports
2 x USB 3.1 ports
2 x USB 3.0 ports
1 x VGA port
4 x RJ-45 ports
1 x RJ-45 port (One for ASMB9-
iKVM) (Optional)
2 x USB 3.1 ports
2 x USB 3.0 ports
1 x VGA port
1 x External Serial Port
4 x RJ-45 ports
1 x RJ-45 port (One for ASMB9-
iKVM) (Optional)
Switch/LED
Rear Switch/LED:
1 x Q-Code/Port 80 LED
1 x Power switch
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
LAN 1-4 LED
OS Support Please nd the latest OS support from http://www.asus.com/
Management
Solution
Software ASUS Control Center
Out of Band
Remote
Management
Optional ASMB9-iKVM for KVM-over-IP
Regulatory Compliance BSMI, CE, C-TICK, FCC, CCC (Class A)
Dimension (HH x WW x DD)
615mm x 444mm x 44mm (1U)
(24.21” x 17.48” x 1.73”)
Net Weight Kg (CPU, DRAM &
HDD not included)
18.99 Kg 17.16 Kg
Power Supply
(following different
congurationbyregion)
1+1 Redundant 450W 80 PLUS
Gold Power Supply
Rating: 100-127/200-240Vac,
5.5A/3A (for each inlet), 50-60Hz,
Class 1
Single 400W 80 PLUS Gold
Power Supply
Rating: 100-240Vac, 6A-3A 50-
60Hz, Class 1
Environment
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 70°C
Non operating humidity: 20% ~ 90% ( Non condensing)
*Specicationsaresubjecttochangewithoutnotice.
