Chapter 1: Product Introduction
1-4
1.3 Systemspecications
The ASUS RS300-E10 Series is a 1U barebone server system featuring the ASUS P11C-
C/4L/SYS Server Board. The server supports Intel
®
LGA1151 Intel
®
Xeon
®
E-21XX/E-22XX
Processor plus other latest technologies through the chipsets onboard.
Model Name RS300-E10-RS4 RS300-E10-PS4
Processor / System Bus
1 x Socket LGA1151
Intel
®
Xeon
®
processor E-21xx/E-22xx product family
Intel
®
8th/9th Generation Core™ i3 processors
Intel
®
Pentium™ processors
Intel
®
Celeron™ processors
Core Logic Intel
®
C242 Chipset
Memory
Total Slots 4 (2 Channels)
Capacity
Maximum up to 128GB (UDIMM)
Memory Type
DDR4 2666 / 2400 ECC / non-ECC UDIMM
* Refer to ASUS server AVL for the latest update
Memory Size
32GB, 16GB, 8GB, 4GB (UDIMM)
* Refer to ASUS server AVL for the latest update
Expansion
Slots
Total PCI/PCI-X /
PCI-E Slots
2
Slot Type
1 x PCI-E x16 (x8 Gen3 Link)
1 x PCI-E x8 (x8 Gen3 Link)
Disk
Controller
SATA Controller
Intel
®
C242
6 x SATA 6Gb/s ports (4 by miniSAS HD) with 2 x M.2 (NGFF
22110/2280/2260/2242, PCI-E NGFF1 x2 link, NGFF2 x1 link
or SATA signal, gray SATA port will disabled when M.2 is SATA
signal)
Intel
®
RSTe (Windows & Linux)
(Supports software RAID 0, 1, 10, & 5)
SAS Controller
Optional:
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 16-port SAS 12G HW RAID card
ASUS PIKE II 3108-8i 16-port 2G SAS 12G HW RAID card
Storage
Bays
I = internal
A or S will be hot-
swappable
4 x 3.5” Hot-Swap HDD Bays
2 x 2.5” Internal SSD Bays
2 x M.2 (NGFF 22110/2280/2260/2242)
Networking LAN 4 x Intel
®
I210AT + 1 x Mgmt LAN
Graphic VGA Aspeed AST2500 32MB
Auxiliary Storage Device Bay
(Floppy / Optical Drive)
1 x Slim-type Optical Drive Bay
Options: No Device / DVD-RW / DVD ROM
Front I/O Ports
2 x USB 3.0 ports
1 x VGA port*
* The system supports a total of 1 VGA output only. The front VGA port is
designed for connecting a VGA device during debugging only.
