ASUS RS300-E10 Series

4-13

3. Micro SD card slot (MSD1)

Your motherboard supports SD Memory Card v2.00 (SDHC) / v3.00 (SDXC).

Disconnect all power (including redundant PSUs) from the existing system before you add

or remove a Memory Card, then reboot the system to access the Memory Card.

• This Micro SD card slot functions only when you install the ASUS ASMB9

Management card.

• Some memory cards may not be compatible with your motherboard. Ensure that you

use only compatible memory cards to prevent loss of data, damage to your device, or

memory card, or both.
