![Asus RS300-E10-PS4 [118/164] Tool menu](/views2/1771505/page118/bg76.png)
5-38
Chapter 5: BIOS Setup
5.10 Event Logs menu
TheEventLogsmenuitemsallowyoutochangetheeventlogsettingsandviewthesystem
event logs.
5.9 Tool menu
5.10.1 Change Smbios Event Log Settings
Press<Enter>tochangetheSmbiosEventLogconguration.
ASUS EZ Flash
Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>. Refer to the
ASUS EZ Flash Utility section for details.
Enabling/Disabling Options
Smbios Event Log [Enabled]
ChangethistoenableordisableallfeaturesofSmbiosEventLoggingduringboot.
Congurationoptions:[Disabled][Enabled]
The following item appears only when you set the Smbios Event Log to [Enabled].
Erasing Settings
Erase Event Log [No]
ChooseoptionsforerasingSmbiosEventLog.Erasingisdonepriortoanyloggingactivation
during reset.
Congurationoptions:[No][Yes,Nextreset][Yes,Everyreset]
When Log is Full [Do Nothing]
ChooseoptionsforreactingtoafullSmbiosEventLog.
Congurationoptions:[DoNothing][EraseImmediately]
Smbios Event Log Standard Settings
Log System Boot Event [Disabled]
This option allows you to enable or disable logging System boot event.
Congurationoptions:[Disabled][Enabled]
Allvalueschangedheredonottakeeffectuntilcomputerisrestarted.
