Asus RS300-E10-PS4 [13/164] Serial number label

ASUS RS300-E10 Series

1-3

4 3 2 1

1.2 Serial number label

Before requesting support from the ASUS Technical Support team, you must take note of the

product’s serial number containing 12 characters such as xxS0xxxxxxxx shown as the gure

below. With the correct serial number of the product, ASUS Technical Support team members

can then offer a quicker and satisfying solution to your problems.

xxS0xxxxxxxx

RS300-E10-RS4

4 3 2 1

xxS0xxxxxxxx

RS300-E10-PS4
