5-42
Chapter 5: BIOS Setup
5.11.2 Bmc self test log
AllowsyoutochangetheSELeventlogconguration.
Enabling/Disabling Options
SEL Components [Enabled]
Allows you to enable or disable event logging for error/progress codes during boot.
Congurationoptions:[No][Yes,Onnextreset][Yes,Oneveryreset]
• ThefollowingitemsarecongurableonlywhenyousetSELComponentsto[Enabled].
• Allvalueschangedheredonottakeeffectuntilcomputerisrestarted.
Erasing Settings
Erase SEL [No]
AllowsyoutochooseoptionsforerasingSEL.
Congurationoptions:[No][Yes,Onnextreset][Yes,Oneveryreset]
When SEL is Full [Do Nothing]
AllowsyoutochooseoptionsforreactionstoafullSEL.
Congurationoptions:[DoNothing][EraseImmediately]
Custom EFI Logging Options
Log EFI Status Codes [Error code]
Allows you to select which codes to log.
Congurationoptions:[Disabled][Both][Errorcode][Progresscode]
Erase Log [Yes, On every reset]
ChooseoptionsforerasingSmbiosEventLog.Erasingisdonepriortoanylogging
activation during reset.
Congurationoptions:[No][Yes,Oneveryreset]
When Log is Full [Clear Log]
AllowsyoutochooseoptionsforreactionstoafullSmbiosEventLog.
Congurationoptions:[ClearLog][Donotloganymore]
