Error Codes and LED Indication Si21-205A
140 Troubleshooting
Indoor Unit
Indoor
Unit
LED
Display
Remote
Controller
Display
Location of Malfunction Contents of Malfunction
Details of
Malfunction
(Reference
Page)
H1P Other
than PC
Board
PC Board
Outdoor
Unit
Indoor
Unit
Remote
Controller
5
————Normal → to outdoor unit —
5
A1 —— — Failure of indoor unit PC
board (For self-diagnosis by
LED, refer to p.138.)
142
4
3
5
A3 ———Malfunction of drain water
level system
143
5
AF
———Float switch operation
during compressor stop
145
5
A6
(FHQ only)
— — Indoor unit fan motor
overload / overcurrent / lock
146,147
5
A7
—
— Swing flap motor
Malfunction / Lock
149
5
AJ — — Failure of capacity setting 151
5
C4 — — Malfunction of heat
exchanger temperature
sensor system (R2T)
152
5
C5 — — Malfunction of heat
exchanger temperature
sensor system (R3T)
153
5
C9 — — Malfunction of suction air
temperature sensor system
154
5
CJ ——
— Malfunction of remote
control air temperature
sensor system
155
