Si21-205A Indoor Unit
Function and Control 75
1.2 Electric Function Parts
FFQ – BV1B
FHQ – BUV1B
Capacity 25 35 50 60 Remarks
Wired remote controller BRC1C517
(BRC1C61 for Australia)
Optional
Accessory
Wireless remote
controller
Heat pump BRC7E530W
Optional
Accessory
Cooling only BRC7E531W
Electronic control unit [2P095006-2] EC0280
Fan motor [3P104408-1] 4P 55W
Fan motor capacitor 4.0MF 440VAC
Swing flap motor MP35HCA
[3P080801-1]
Float switch [4P104167-1] FS-0211
Drain pump [3P103929-1]
PLD-12230 DM-17
Capacity 35 50 60 Remarks
Wired remote controller BRC1C517 Optional
Accessory
Wireless remote
controller
Heat pump BRC7E63W
Optional
Accessory
Cooling only BRC7E66
Electronic Control Unit [2P095007-1]
EC0227
Fan Motor [3PN04213-1] 4P 62W
Fan Motor Capacitor 3.0MF 400V
Swing Motor [3PN04208-1]
