Specifications Si21-205A
14 Specifications
1.2 Ceiling Suspended Type
1.2.1 35 class
230V, 50Hz
Notes:
★
1. Nominal capacities are based on the following conditions:
★
2. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
3. In case of drain piping for outdoor unit, drain piping kit (option) is needed.
★
4. Amount of additional charge of refrigerant is 20g/m for piping length exceeding 10m.
Model
Indoor Units FHQ35BUV1B FHQ35BUV1B
Outdoor Units RXS35BVMB RKS35BVMB
★
1 Cooling Capacity (Min.~Max.)
kW 3.4 (1.0~3.7) 3.4 (1.0~3.7)
Btu/h 11,600 (3,400~12,600) 11,600 (3,400~12,600)
kcal/h 2,920 (860~3,180) 2,920 (860~3,180)
★
1 Heating Capacity (Min.~Max.)
kW 4.1 (1.0~5.0) —
Btu/h 14,000 (3,400~17,050) —
kcal/h 3,530 (860~4,300) —
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm I. D
φ
20×O. D
φ
26 I. D
φ
20×O. D
φ
26
Indoor Units FHQ35BUV1B FHQ35BUV1B
Color White White
Dimensions H×W×D mm 195×960×680 195×960×680
Coil
Type Cross Fin Coil (Multi Louver Fins and Hi-XSS Tubes)
Row×Stages×Fin Pitch 2×12×1.75 2×12×1.75
Fan
Model D09P62A-20 D09P62A-20
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Air Flow Rate m³/min. (H) 13 (L) 10 (H) 13 (L) 10
Weight kg 24 24
Remote Controller
(Option)
Wired BRC1C517 BRC1C517
Wireless BRC7E63W BRC7E66
Outdoor Units RXS35BVMB RKS35BVMB
Color Ivory white Ivory white
Dimensions H×W×D mm 560×695×265 560×695×265
Coil
Type Cross Fin Coil (Waffle Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×24×1.5 2×24×1.5
Comp.
Model 1YC23GXD#A 1YC23GXD#A
Type Hermetically Sealed Swing type Hermetically Sealed Swing type
Motor Output kW 0.6 0.6
Fan
Model MF-220-19-6-2 MF-220-19-6-2
Type Propeller Propeller
Motor Output W 19 19
Air Flow Rate
Cooling m³/min. (H) 25.3 (L) 17.0 (H) 25.3 (L) 17.0
Heating m³/min. (H) 22.8 (L) 15.3 —
Weight kg 37 37
Ref.Piping
Max. Length m 20 25
Max. Height Difference m 15 15
Refrigerant
Model R410A R410A
Charge kg 1.06 1.06
Ref. Oil
Model FVC50K FVC50K
Charge L 0.40 0.40
Drawing No.
3D040588
3D040589
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping length
Indoor: 27°CDB, 19°CWB
Outdoor: 35°CDB, 24°CWB
Indoor: 20°CDB
Outdoor: 7°CDB, 6°CWB
7.5m
