Si21-205A Error Codes and LED Indication
Troubleshooting 141
Outdoor Unit
★
: Displayed only when system-down occurs.
Code Indication Description
Reference Page
25/35 class 50/60 class
E5★
OL activation (compressor overload) 164 195
E6★
Compressor lock 165 196
E7
DC fan lock — 197
E8
Input over current detection 166 198
EA
Four way valve abnormality 167 200
F3
Discharge pipe temperature control 169 202
F6
High pressure control in cooling 184 217
H6
Position sensor abnormality 170 203
H8
CT or related abnormality 171 204
H9
Outdoor air thermistor or related abnormality 173 206
J3
Discharge pipe thermistor or related abnormality 173 206
J6
Heat exchanger thermistor or related abnormality 173 206
L3
Electrical box temperature rise 175 208
L4
Radiation fin temperature rise 177 210
L5
Output over current detection 179 212
P4
Radiation fin thermistor or related abnormality 173 206
U0★
Insufficient gas 181 214
U2
Over-voltage detection 183 —
Low-voltage detection — 216
