Daikin FHQ100BUV1B [246/340] Remove the horizontal vane
![Daikin FHQ100BUV1B [246/340] Remove the horizontal vane](/views2/1773521/page246/bgf6.png)
Si21-205A FFQ25/35/50/60BV1B
Removal Procedure 235
4
Remove the horizontal
vane.
Step
Procedure Points
(S2646)
