Daikin FHQ100BUV1B [280/340] The pcb has eight hooks
![Daikin FHQ35BUV1B [280/340] The pcb has eight hooks](/views2/1773521/page280/bg118.png)
Si21-205A Outdoor Unit (25/35 class)
Removal Procedure 269
5
Undo the eight hooks
and the PCB can be
disengaged.
The PCB has eight hooks.
6
Disconnect the three
wires from the PCB.
Step Procedure Points
