Si21-205A FFQ25/35/50/60BV1B
Removal Procedure 233
5
Turn the provisional
hanger to disengage it
from the hook of switch
box, and slide the
decoration panel in the
arrow direction to
remove the panel.
Step
Procedure Points
(S2640)
(S2641)
