Si21-205A Specifications
Specifications 15
1.2.2 50 class
230V, 50Hz
Notes:
★
1. Nominal capacities are based on the following conditions:
★
2. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
3. In case of drain piping for outdoor unit, drain piping kit (option) is needed.
★
4. Amount of additional charge of refrigerant is 20g/m for piping length exceeding 10m.
Model
Indoor Units FHQ50BUV1B FHQ50BUV1B FHQ50BUV1B
Outdoor Units RXS50BVMB RKS50BVMB RS50BVMB
★
1 Cooling Capacity (Min.~Max.)
kW 5.0 (0.9~5.6) 5.0 (0.9~5.6) 5.0
Btu/h 17,050 (3,050~19,100) 17,050 (3,050~19,100) 17,050
kcal/h 4,300 (770~4,820) 4,300 (770~4,820) 4,300
★
1 Heating Capacity (Min.~Max.)
kW 6.0 (0.9~7.0) — —
Btu/h 20,450 (3,050~23,900) — —
kcal/h 5,160 (770~6,020) — —
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
φ
12.7
Drain mm I. D
φ
20×O. D
φ
26 I. D
φ
20×O. D
φ
26 I. D
φ
20×O. D
φ
26
Indoor Units FHQ50BUV1B FHQ50BUV1B FHQ50BUV1B
Color White White White
Dimensions H×W×D mm 195×960×680 195×960×680 195×960×680
Coil
Type Cross Fin Coil (Multi Louver Fins and Hi-XSS Tubes)
Row×Stages×Fin Pitch 3×12×1.75 3×12×1.75 3×12×1.75
Fan
Model D09P62A-20 D09P62A-20 D09P62A-20
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output W 62 62 62
Air Flow Rate m³/min. (H) 13 (L) 10 (H) 13 (L) 10 (H) 13 (L) 10
Weight kg 25 25 25
Remote Controller
(Option)
Wired BRC1C517 BRC1C517 BRC1C517
Wireless BRC7E63W BRC7E66 BRC7E66
Outdoor Units RXS50BVMB RKS50BVMB RS50BVMB
Color Ivory white Ivory white Ivory white
Dimensions H×W×D mm 735×825×300 735×825×300 735×825×300
Coil
Type Cross Fin Coil (Waffle Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 1×32×1.6 1×32×1.6 1×32×1.6
Comp.
Model 2YC32HXD 2YC32HXD 2YC32HXD
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Motor Output kW 1.5 1.5 1.5
Fan
Model KFD-380-53-8C KFD-380-53-8C KFD-380-53-8C
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Air Flow Rate
Cooling m³/min. (H) 47.7 (L) 44.1 (H) 47.7 (L) 44.1 (H) 47.7 (L) 44.1
Heating m³/min. (H) 44.1 (L) 44.1 — —
Weight kg 49 49 49
Ref.Piping
Max. Length m 30 30 30
Max. Height Difference m 20 20 20
Refrigerant
Model R410A R410A R410A
Charge kg 1.20 1.20 1.20
Ref. Oil
Model FVC50K FVC50K FVC50K
Charge L 0.65 0.65 0.65
Drawing No. 3D040590
3D040591
3D040592
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping length
Indoor: 27°CDB, 19°CWB
Outdoor: 35°CDB, 24°CWB
Indoor: 20°CDB
Outdoor: 7°CDB, 6°CWB
7.5m
