Outdoor Unit (25/35 class) Si21-205A
278 Removal Procedure
3
When restoring the
partition plate, fit the
hook into the bottom
frame.
2. Remove the reactor.
1
The reactor can be
released by removing
the fixed screw.
3. Remove the reactor
assembly.
1
Remove the one screw
fixing the reactor
assembly to the bottom
frame.
Step Procedure Points
