ELECTRICAL DATA
RP125B7W1/T1
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA TOCA MFA LRA RLA kW FLA kW FLA
FHYCP125/FUYP125 RP125B7W1 50-400/230
Max. 50Hz-440V/253V
Min. 50Hz-360V/197V
12.7 16.4 20 57.3 8.1
0.085
+
0.08
0.84
+
0.7
0.09 1.0
FHYP125 RP125B7W1 50-400/230 12.6 16.3 20 57.3 8.1
0.085
+
0.08
0.84
+
0.7
0.13 0.9
FHYBP125 RP125B7W1 50-400/230 13.1 16.8 20 57.3 8.1
0.085
+
0.08
0.84
+
0.7
0.225 1.4
FDYP125 RP125B7W1 50-400/230 15.9 19.6 20 57.3 8.1
0.085
+
0.08
0.84
+
0.7
0.5 4.2
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA TOCA MFA LRA RLA kW FLA kW FLA
FHYCP125/FUYP125 RP125B7T1 50-230
Max. 50Hz-253V
Min. 50Hz-197V
19.7 26.5 32 98.8 13.7
0.085
+
0.08
0.84
+
0.7
0.09 1.0
FHYP125 RP125B7T1 50-230 19.6 26.4 32 98.8 13.7
0.085
+
0.08
0.84
+
0.7
0.13 0.9
FHYBP125 RP125B7T1 50-230 20.1 26.9 32 98.8 13.7
0.085
+
0.08
0.84
+
0.7
0.225 1.4
FDYP125 RP125B7T1 50-230 22.9 29.7 32 98.8 13.7
0.085
+
0.08
0.84
+
0.7
0.5 4.2
3TW23269-2
RP200B7W1
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA MFA LRA RLA kW FLA kW FLA
FDYP200B7V1 RP200B7W1 50-400
Max. 50Hz-440V
Min. 50Hz-360V
19.0 25 16 98 12.9
0.19
+
0.23
1.28
+
1.43
650 6.8
FDYP250B7V1 RP250B7W1 50-400
Max. 50Hz-440V
Min. 50Hz-360V
22.7 32 16 108 16.0
0.14
+
0.23
1.1
+
1.43
1000 7.6
3TW23611-2
SYMBOLS
MCA : Min. Circuit Amps
TOCA : Total Over Current Amps
MFA : Max. Fuse Amps (see note 7)
LRA : Locked Rotor Amps
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Rated motor output
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. TOCA means the total value of each OC set
3. Voltage range
Units are suitable for use on electrical systems where
voltage supplied to unit terminals is not below or above
listed operation range limits
4. Maximum allowable voltage unbalance between phases is
2%
5. MCA/MFA
MCA = 1.25 x RLA + ea. FLA
MFA ≤ 2.25 x RLAA + ea. FLA
(next lower standard fuse rating, min.15A)
6. Select wire size based on the larger value of MCA or TOCA
7. Instead of fuse, use circuit breaker
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
2
Specifications
13
2
9
• Split - Sky Air • Outdoor Units
