Daikin RP71B7V1 [6/48] Specifications
![Daikin RP125B7T1 [6/48] Specifications](/views2/1783025/page6/bg6.png)
TECHNICAL SPECIFICATIONS
OUTDOOR UNITS RP100B7V1/W1/T1 RP125B7W1/T1
RP200B7W1
RP250B7W1
DIMENSIONS Unit H mm 1,215 1,215 1,220 1,440
W mm 880 880 1,290 1,290
D mm 320 320 700 700
WEIGHT Unit kg 103/98/98 100 194 206
MATERIAL Unit Painted galvanised steel plate
COLOUR Unit Ivory white
SOUND LEVEL Sound pressure (1) high dBA 53 53 56 56
lowdBA----
Sound power (2) high dBA 66 67 77 77
FAN Air flow rate high m
3
/min 94 94 170 175
Speed steps 3 steps 3 steps 1 Step 1 Step
high rpm ----
lowrpm----
Type ----
Qty x model 2 x P47L11S 2 x P47L11S 1 x P55J11F 1 x P55J11F
Qty x motor output W 1 x (80+85) 1 x (80+85) 1 x (230+190) 1 x (230+140)
HEAT EXCHANGER Type Hi-XA cooling tube, non symm. waffle louvre
Rows x stages x fin pitch mm 2 x 54 x 2.0 2 x 54 x 2.0 2 x 40 x 2 2 x 50 x 2
Face area m
2
1,022 1,022 1.57 1.97
REFRIGERANT
CIRCUIT
Refrigerant type R407C
Refrigerant charge kg 3.6 3.9 7.5 9.2
Number of circuits ----
Refrigerant control Expansion valve (electronic type) Expansion valve
COMPRESSOR Type Hermetically sealed scroll type
Qty x model 1 x JT125FA-V1N
1 x T125FA-YE
1 x JT125FA-T1
1 x JT160FA-YE
1 x JT160FA-T1
1 x JT236DA-YE@2 1 x JT300DA-YE@2
Motor output x no W 3,000 x 1 3,750 x 1 5,500 x 1 7,500 x 1
Number of cylinders ----
Speed rpm - - 2,900 2,900
Oil type Daphne FVC68D Daphne FVC68D Daphne*FVC68D Daphne*FVC68D
Oil charge volume ! 1.5 1.5 4 4
Crankcase heater W - - 50 72
PIPING CONNECTIONS liquid mm φ9.5 φ9.5 φ12.7 x 0.90 φ15.9 x 0.95
gas mm φ19.1 φ19.1 φ28.60 x 1.15 φ28.60 x 1.15
drain
mm φ26x3 φ26x3 φ26x6 φ26x6
INSULATION
MATERIAL
Heat insulation Both liquid and gas pipes
Safety devices High and low pressure switch, thermal
protector for indoor and outdoor fan motor,
overcurrent relay (compressor), reverse phase
protection (W1/T1) fuse.
High and low pressure switches, thermal
protector for indoor and outdoor fan motor,
fuse, over current relay (compressor), reverse
phase protector, compressor thermal
protector
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
2
Specifications
13
2
4
• Split - Sky Air • Outdoor Units
