Daikin RP71B7V1 [25/48] Capacity tables

Daikin RP71B7T1 [25/48] Capacity tables
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
NOTES
1. Ratings shown are net capacities which include a deduction for
indoor fan motor heat
2. Shows nominal capacities
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.29 x 60 x AFR (m3/min) x (DB-EDB).
Add SHC* to SHC if SHC > TC, then TC equal SHC
4. Direct interpolation is permissible.
Do not extrapolate..
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
RP(200∼250)B7W1 + FDYP(200∼250)B7V1
Cooling capacity
Model FDYP200 FDYP250
AFR 69 89
BF 0.25 0.25
Outdoor
Indoor Outdoor temperature (°C)
EWB
(°C)
EDB
(°C)
20 25 32 35 40 46
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
RP200
12.0 18.0 17.9 15.2 6.51 17.2 14.7 7.00 16.2 14.0 7.84 15.8 13.8 8.25 15.1 13.3 9.04 14.4 12.9 10.10
14.0 20.0 19.2 15.3 6.60 18.4 14.8 7.09 17.4 14.2 7.96 16.9 13.9 8.38 16.3 13.5 9.17 15.5 13.0 10.24
16.0 22.0 20.5 15.4 6.70 19.7 14.9 7.21 18.6 14.3 8.08 18.1 14.0 8.51 17.4 13.6 9.31 16.7 13.1 10.40
18.0 25.0 21.8 16.3 6.80 21.0 15.8 7.33 19.8 15.2 8.21 19.4 15.0 8.64 18.6 14.6 9.45 17.8 14.1 10.56
19.0 27.0 22.5 17.2 6.86 21.6 16.8 7.39 20.5 16.1 8.28 20.0 15.9 8.71 19.3 15.5 9.53 18.4 15.0 10.64
22.0 30.0 24.7 17.2 7.04 23.8 16.8 7.57 22.6 16.2 8.49 22.0 15.9 8.94 21.2 15.5 9.78 20.3 15.0 10.91
24.0 32.0 26.2 17.2 7.16 25.3 16.8 7.71 24.0 16.2 8.65 23.5 15.9 9.11 22.7 15.5 9.95 21.7 15.0 11.10
RP250
12.0 18.0 22.4 19.1 8.03 21.5 18.5 8.63 20.2 17.7 9.67 19.7 17.3 10.18 18.9 16.8 11.14 18.0 16.2 12.46
14.0 20.0 24.0 19.2 8.14 23.0 18.6 8.75 21.7 17.8 9.82 21.2 17.5 10.34 20.3 17.0 11.30 19.4 16.4 12.63
16.0 22.0 25.6 19.3 8.26 24.6 18.7 8.89 23.2 17.9 9.96 22.7 17.6 10.49 21.8 17.1 11.48 20.8 16.5 12.82
18.0 25.0 27.2 20.5 8.39 26.2 19.9 9.04 24.8 19.2 10.12 24.2 18.8 10.65 23.3 18.3 11.65 22.3 17.7 13.02
19.0 27.0 28.1 21.7 8.46 27.0 21.1 9.11 25.6 20.3 10.21 25.0 20.0 10.74 24.1 19.5 11.75 23.0 18.9 13.12
22.0 30.0 30.9 21.6 8.68 29.7 21.1 9.34 28.2 20.3 10.47 27.6 20.0 11.03 26.5 19.5 12.05 25.4 18.9 13.45
24.0 32.0 32.8 21.7 8.83 31.6 21.1 9.51 30.0 20.4 10.67 29.4 20.0 11.23 28.3 19.5 12.27 27.1 18.9 13.68
3TW23612-1A
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
3
Capacity tables
13
3
23
• Split - Sky Air • Outdoor Units
