1 In case of installing
one unit per row.
2 In case of installing
multiple units (2 units
or more) in lateral
connection per row.
2 Installation of multiple units in
lateral connection (2units or
less).
Relation of dimensions of H, A, and
L are shown in the table below.
LA
L ≤ H
0<L≤ 1/2 H 150 (250)
1/2H<L 200(300)
H < L Set the frame to be L<=H
(D) In case of stacked installation
1 In case obstacles exist in front of the
outlet side.
Do not stack more than one unit.
About 100mm is required as the
dimension for laying the upper outdoor
unit’s drain pipe.
Get the portion A sealed so that air from
the outlet does not bypass.
Relation of dimensions of H, A, and L are
shown in the table below.
LA
L ≤ H
0<L≤ 1/2 H 150 (250)
1/2H<L 200(300)
H < L Installation impossible
2 In case obstacles exist in front of the
air inlet.
Do not stack more than one unit.
About 100mm is required as the
dimension for laying the upper outdoor
unit’s drain pipe.
Get the portion A sealed so that air from
the outlet does not bypass.
(E) In case of multiple-low installation
(for roof top use, etc.).
+ Where there are obstacles
above the unit.
+ Where there are no obstacles above
the unit.
Get the lower part of the frame sealed so
that air from the outlet does not bypass
Do not install more than 2 units
1 Installation of single unit.
2 Installation of multiple units in lateral
connection (2 units or more).
Relation of dimensions of H, A, and L are
shown in the table below.
LA
L ≤ H
0<L≤ 1/2 H 750<1250>
1/2H<L 1000<1500>
H < L Set the frame to be L<=H
Relation of dimensions of H, A, and L are
shown in the table below.
LA
L ≤ H
0<L≤ 1/2 H 1000<1500>
1/2H<L 1250<1750>
H < L Set the frame to be L<=H
Pattern 2
Where obstacle in front of the air outlet
is lower than the unit.
1 Installation of single unit.
2 Installation of multiple units in lateral
connection (2 units or more).
Relation of dimensions of H, A, and L
are shown in the table below.
LA
0<L≤ 1/2 H 150 (250)
1/2H<L 200(300)
+ Where there are obstacles above the
unit.
1 Installation of single unit.
Relation of dimensions of H, A, and L are
shown in the table below.
LA
L ≤ H
0<L≤ 1/2 H 50 (100)
1/2H<L 100(200)
H < L Set the frame to be L<=H
Get the lower part of the frame sealed so
that air from the outlet does not bypass
Get the lower part of the frame sealed so
that air from the outlet does not bypass
Get the lower part of the frame sealed so
that air from the outlet does not bypass
Do not install more than 2 units
500 or less
150 or more (250)
500 or less
20 mm or
more
200 or more (300)
50 or more (100)
500 or more (1000)
20 mm or more
20 mm or more
1000 or more (1500)
500 or less
500 or more (1000)
500 or less
20 mm or
more
1000 or more (1500)
20 mm or more
1000 mm or more
20 mm or more
200 or more (300)
50 or
more (100)
1000 or more (2000)
100 or more (200)
500 or more (1000)
20 mm or more
20 mm or more
2000 or more (3000)
400 or more (600)
1000 or more (1500)
1000 mm or more
1000 mm or more
100 or more
1000 mm or more
DU427-826
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
11
Installation
13
11
44
• Split - Sky Air • Outdoor Units
