Daikin RP71B7V1 [16/48] Capacity tables
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

Daikin RP71B7V1 [16/48] Capacity tables

Daikin RP71B7W1 [16/48] Capacity tables
R45GZ7W11 + FHC45BZ7V1
Cooling capacity 400V [50Hz]
Model FHC..B
AFR 15
BF 0.16
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 4.80 3.40 1.47 4.56 3.30 1.63 4.22 3.18 1.86 4.06 3.12 1.97 3.82 3.04 2.12 3.53 2.93 2.32
14.0 20.0 5.13 3.47 1.51 4.89 3.38 1.67 4.54 3.25 1.90 4.39 3.20 2.00 4.15 3.11 2.16 3.85 3.00 2.36
16.0 22.0 5.45 3.54 1.56 5.21 3.45 1.71 4.87 3.32 1.94 4.71 3.27 2.04 4.47 3.18 2.20 4.18 3.07 2.40
18.0 25.0 5.78 3.61 1.59 5.53 3.52 1.76 5.19 3.40 1.98 5.04 3.35 2.08 4.79 3.25 2.24 4.50 3.14 2.43
19.0 27.0 5.94 3.65 1.61 5.69 3.56 1.78 5.35 3.43 2.00 5.20 3.38 2.10 4.96 3.28 2.26 4.66 3.18 2.46
22.0 30.0 6.42 3.75 1.67 6.17 3.66 1.83 5.83 3.54 2.06 5.69 3.49 2.16 5.44 3.40 2.32 5.14 3.28 2.52
24.0 32.0 6.74 3.82 1.71 6.50 3.73 1.87 6.15 3.61 2.10 6.01 3.56 2.20 5.76 3.47 2.36 5.46 3.36 2.56
R45GZ7W11 + FH45BZV1
+ FHK45BZV1
Cooling capacity 400V [50Hz]
Model FH..B FHK..B
AFR 13 12
BF 0.09 0.18
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 4.78 3.38 1.44 4.54 3.28 1.60 4.20 3.16 1.83 4.04 3.10 1.93 3.81 3.02 2.08 3.52 2.91 2.28
14.0 20.0 5.11 3.45 1.48 4.87 3.36 1.64 4.52 3.23 1.86 4.37 3.18 1.97 4.13 3.09 2.12 3.84 2.98 2.31
16.0 22.0 5.43 3.52 1.53 5.19 3.43 1.68 4.85 3.30 1.90 4.69 3.25 2.00 4.45 3.16 2.15 4.16 3.05 2.35
18.0 25.0 5.76 3.59 1.56 5.51 3.50 1.72 5.17 3.38 1.94 5.02 3.33 2.04 4.77 3.23 2.20 4.48 3.12 2.39
19.0 27.0 5.92 3.63 1.58 5.67 3.54 1.74 5.33 3.41 1.97 5.18 3.36 2.06 4.94 3.26 2.22 4.64 3.16 2.42
22.0 30.0 6.40 3.73 1.64 6.15 3.64 1.80 5.81 3.52 2.02 5.67 3.47 2.12 5.42 3.38 2.28 5.12 3.26 2.47
24.0 32.0 6.71 3.80 1.68 6.48 3.71 1.84 6.13 3.59 2.06 5.99 3.54 2.15 5.74 3.45 2.31 5.44 3.34 2.51
Correction TC SHC PI
FH..B +0.02 +0.04 -0.01
FHK..B 0.0 +0.10 0.0
R45GZ7W11 + FHB45GZ7V1
Cooling capacity 400V [50Hz]
Model FHB
AFR 11.5
BF 0.15
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 4.52 3.20 1.49 4.30 3.10 1.66 3.98 2.99 1.89 3.83 2.94 1.99 3.60 2.86 2.15 3.33 2.76 2.35
14.0 20.0 4.83 3.26 1.53 4.61 3.18 1.69 4.28 3.06 1.93 4.14 3.01 2.03 3.91 2.93 2.19 3.63 2.82 2.39
16.0 22.0 5.14 3.33 1.58 4.91 3.25 1.73 4.59 3.12 1.97 4.44 3.08 2.07 4.21 2.99 2.23 3.94 2.89 2.43
18.0 25.0 5.45 3.40 1.62 5.21 3.31 1.78 4.89 3.20 2.00 4.75 3.15 2.11 4.51 3.06 2.28 4.24 2.95 2.47
19.0 27.0 5.60 3.43 1.64 5.36 3.35 1.80 5.04 3.23 2.03 4.90 3.18 2.13 4.67 3.09 2.29 4.392 .99 2.50
22.0 30.0 6.05 3.53 1.69 5.81 3.44 1.88 5.49 3.33 2.09 5.36 3.28 2.19 5.13 3.20 2.35 4.84 3.09 2.56
24.0 32.0 6.35 3.59 1.73 6.13 3.51 1.90 5.80 3.40 2.13 5.66 3.35 2.23 5.43 3.26 2.39 5.15 3.16 2.59
3TW00904-2B
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor
fan motor heat
2. Shows nominal capacities
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.34 x 60 x AFR (m3/min) x (DB-EDB)/1000.
Add SHC* to SHC if SHC > TC, then TC equal SHC
4. Direct interpolation is permissible Do not extrapolate.
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
3
Capacity tables
13
3
14
• Split - Sky Air • Outdoor Units
