R60GZ7W1 + FT60GZV1NB
Cooling capacity 400V [50Hz]
Model FT
AFR 13.3
BF 0.15
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 6.09 4.46 1.74 5.82 4.39 1.96 5.44 4.28 2.26 5.28 4.24 2.39 5.01 4.16 2.60 4.69 4.07 2.86
14.0 20.0 6.44 4.52 1.79 6.17 4.45 2.01 5.79 4.34 2.31 5.63 4.30 2.44 5.36 4.22 2.66 5.04 4.13 2.92
16.0 22.0 6.79 4.58 1.85 6.52 4.51 2.06 6.14 4.40 2.37 5.98 4.36 2.50 5.71 4.28 2.71 5.38 4.19 2.97
18.0 25.0 7.14 4.64 1.90 6.87 4.57 2.12 6.49 4.46 2.42 6.33 4.42 2.55 6.06 4.34 2.77 5.73 4.25 3.03
19.0 27.0 7.31 4.67 1.93 7.04 4.60 2.15 6.66 4.49 2.45 6.50 4.45 2.58 6.23 4.37 2.80 5.91 4.28 3.06
22.0 30.0 7.83 4.76 2.01 7.56 4.69 2.23 7.18 4.58 2.53 7.02 4.54 2.66 6.75 4.46 2.88 6.43 4.37 3.14
24.0 32.0 8.18 4.82 2.07 7.91 4.75 2.28 7.53 4.64 2.59 7.37 4.60 2.72 7.10 4.52 2.93 6.78 4.43 3.19
3TW02102-1
R60GZ7W1 + FHC60
+FH60
+ FHK60
Cooling capacity 400V [50Hz]
Model FHC FH FHK
AFR 19.0 18.0 17.0
BF 0.10 0.10 0.10
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 5.98 4.05 1.89 5.78 3.97 2.07 5.49 3.87 2.35 5.36 3.82 2.47 5.13 3.76 2.70 4.84 3.66 3.01
14.0 20.0 6.32 4.11 1.94 6.12 4.03 2.11 5.81 3.93 2.39 5.67 3.88 2.53 5.43 3.81 2.77 5.12 3.73 3.08
16.0 22.0 6.67 4.18 1.97 6.46 4.09 2.16 6.14 3.99 2.45 5.99 3.94 2.58 5.74 3.87 2.83 5.41 3.79 3.15
18.0 25.0 7.04 4.24 2.01 6.82 4.16 2.21 6.48 4.05 2.51 6.33 4.00 2.64 6.06 3.93 2.89 5.71 3.84 3.21
19.0 27.0 7.23 4.26 2.03 7.01 4.19 2.23 6.66 4.08 2.53 6.50 4.03 2.67 6.22 3.96 2.93 5.86 3.87 3.24
22.0 30.0 7.82 4.35 2.10 7.58 4.27 2.31 7.21 4.18 2.62 7.03 4.13 2.77 6.73 4.05 3.02 6.34 3.96 3.34
24.0 32.0 8.22 4.41 2.15 7.97 4.33 2.36 7.59 4.24 2.68 7.40 4.19 2.83 7.08 4.11 3.08 6.67 4.02 3.41
3TW02102-2A
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
ED*: Dry bulb temperature (°CDB)
TC: Total cooling capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor
fan motor heat
2. Shows nominal capacities
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.34 x 60 x AFR (m3/min) x (DB-EDB)/1000.
Add SHC* to SHC if SHC > TC, then TC equal SHC
4. Direct interpolation is permissible Do not extrapolate.
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
3
Capacity tables
13
3
15
• Split - Sky Air • Outdoor Units
