RP71-100-125B7
3TW23183-1
Outdoor temp. (°CDB)
Allowable range of operation
(pull-down)
Continuous operation range
Indoor temp. (°CWB)
Model name
RP71B7V1 RP100B7W1
RP71B7W1 RP100B7T1
RP71B7T1 RP125B7W1
RP100B7V1 RP125B7T1
Outdoor temp. (°CDB)
Continuous operation
Indoor temp. (°CWB)
RP200-250B7
3TW23613-1
Pull-down period
Notes:
The graph is based on the following conditions:
1. Equivalent piping length 70 m
2. Level difference 30 m
3. Indoor air flow rate 72m
3
/min (200 class)
90m
3
/min (250 class)
Cooling
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
