ELECTRICAL DATA
R45GZ7W11
Connection ratio (%) Indoor unit
Power supply Compressor OFM IFM EH
Hz - Volts Voltage range MCA TOCA MFA LRA RLA W FLA W FLA W FLA
− FT45JZV1NB 50-400
Max. 440V
Min. 360V
4.9 − 15.0 19.0 3.5 45 0.3 40 0.2 −−
− FH45BZ7V1 50-400
Max. 440V
Min. 360V
5.0 − 15.0 19.0 3.5 45 0.3 57 0.3 −−
− FHC45BZ7V1 50-400
Max. 440V
Min. 360V
5.0 − 15.0 19.0 3.5 45 0.3 45 0.3 −−
− FHB45GZ7V1 50-400
Max. 440V
Min. 360V
5.2 − 15.0 19.0 3.5 45 0.3 85 0.5 −−
3TW01931-3
R60GZ7W1
Connection ratio (%) Indoor unit
Power supply Compressor OFM IFM EH
Hz - Volts Voltage range MCA TOCA MFA LRA RLA W FLA W FLA W FLA
− FT60GZV1NB 50-400
Max. 440V
Min. 360V
6.8 − 15 26 4.6 49 0.5 40 0.2 −−
− FHC60BZ7V1 50-400
Max. 440V
Min. 360V
7.7 − 15 26 5.3 49 0.5 45 0.2 −−
3TW02101-2
RP71B7V1/W1/T1
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA TOCA MFA LRA RLA kW FLA kW
FLA
FHYCP71/FUYP71 RP71B7V1 50-230
Max. 50Hz-253V
Min. 50Hz-197V
16.4 23.4 32 71.3 12.1 0.075 0.7 0.045 0.6
FHP71 RP71B7V1 50-230 16.1 23.1 32 71.3 12.07 0.075 0.7 0.057 0.3
FHYP71 RP71B7V1 50-230 16.4 23.4 32 71.3 12.07 0.075 0.7 0.062 0.6
FAYP71 RP71B7V1 50-230 16.1 23.1 32 71.3 12.07 0.075 0.7 0.046 0.3
FHYKP71 RP71B7V1 50-230 16.3 23.3 32 71.3 12.07 0.075 0.7 0.045 0.5
FHYBP71 RP71B7V1 50-230 16.7 23.7 32 71.3 12.07 0.075 0.7 0.125 0.9
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA TOCA MFA LRA RLA kW FLA kW FLA
FHYCP71/FUYP71 RP71B7W1 50-400/230
Max. 50Hz-440V/253V
Min. 50Hz-360/197V
7.1 11.3 16 34.8 4.6 0.075 0.7 0.045 0.6
FHYP71 RP71B7W1 50-400/230 7.1 11.3 16 34.8 4.6 0.075 0.7 0.062 0.6
FAYP71 RP71B7W1 50-400/230 6.8 11.0 16 34.8 4.6 0.075 0.7 0.046 0.3
FHYKP71 RP71B7W1 50-400/230 7.0 11.2 16 34.8 4.6 0.075 0.7 0.045 0.5
FHYBP71 RP71B7W1 50-400/230 7.4 11.6 16 34.8 4.6 0.075 0.7 0.125 0.9
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz - Volts Voltage range MCA TOCA MFA LRA RLA kW FLA kW
FLA
FHYCP71/FUYP71 RP71B7T1 50-230
Max. 50Hz-364V
Min. 50Hz-198V
11.2 16.3 20 58.3 7.9 0.075 0.7 0.045 0.6
FHYP71 RP71B7T1 50-230 11.2 16.3 20 58.3 7.9 0.075 0.7 0.062 0.6
FAYP71 RP71B7T1 50-230 10.9 16.0 20 58.3 7.9 0.075 0.7 0.046 0.3
FHYKP71 RP71B7T1 50-230 11.1 16.2 20 58.3 7.9 0.075 0.7 0.045 0.5
FHYBP71 RP71B7T1 50-230 11.5 16.6 20 58.3 7.9 0.075 0.7 0.125 0.9
3TW23189-2A
SYMBOLS
MCA : Min. Circuit Amps
TOCA : Total Over Current Amps
MFA : Max. Fuse Amps (see note 7)
LRA : Locked Rotor Amps
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Rated motor output
EH : Electric Heater
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. TOCA means the total value of each OC set
3. Voltage range
Units are suitable for use on electrical systems where
voltage supplied to unit terminals is not below or above
listed operation range limits
4. Maximum allowable voltage unbalance between phases is
2%
5. MCA/MFA
MCA = 1,25 x RLA + ea. FLA + 1,25 x EH FLA
MFA ≤ 2,25 x RLA + ea. FLA + 2,25 x EH FLA
(next lower standard fuse rating, min.15A)
6. Select wire size based on the larger value of MCA or TOCA
7. Instead of fuse, use circuit breaker
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
