R35GZ7V11 + FHB35GZ7V1
Cooling capacity 230V [50Hz]
Model FHB..GZ
AFR 11.5
BF 0.15
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 3.60 2.50 1.02 3.45 2.43 1.12 3.24 2.33 1.25 3.15 2.29 1.31 3.00 2.22 1.40 2.82 2.13 1.52
14.0 20.0 3.76 2.53 1.05 3.61 2.46 1.15 3.40 2.36 1.28 3.31 2.32 1.34 3.16 2.25 1.43 2.98 2.17 1.54
16.0 22.0 3.92 2.56 1.08 3.77 2.49 1.17 3.56 2.40 1.30 3.47 2.35 1.36 3.32 2.28 1.46 3.14 2.20 1.57
18.0 25.0 4.07 2.60 1.10 3.92 2.53 1.20 3.71 2.43 1.33 3.62 2.39 1.39 3.47 2.32 1.48 3.29 2.23 1.60
19.0 27.0 4.15 2.62 1.12 4.00 2.55 1.21 3.79 2.45 1.34 3.70 2.41 1.40 3.55 2.34 1.50 3.37 2.25 1.61
22.0 30.0 4.38 2.67 1.15 4.23 2.60 1.25 4.02 2.50 1.38 3.93 2.46 1.44 3.78 2.39 1.53 3.60 2.30 1.65
24.0 32.0 4.54 2.70 1.18 4.39 2.63 1.28 4.18 2.53 1.41 4.09 2.49 1.47 3.94 2.42 1.56 3.76 2.34 1.67
3TW01912-2A
R45GZ7V11 + FT45GAZV1NB
+ FL45GZV1NB
Cooling capacity 230V [50Hz]
Model FT..G FL..G
AFR 11.8 10.8
BF 0.18 0.18
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 4.71 3.33 1.47 4.47 3.24 1.63 4.14 3.12 1.86 4.58 3.15 2.07 3.75 2.98 2.12 3.46 2.87 2.32
14.0 20.0 5.03 3.40 1.51 4.79 3.31 1.67 4.45 3.19 1.90 4.30 3.14 2.00 4.07 3.05 2.16 3.78 2.94 2.36
16.0 22.0 5.35 3.47 1.55 5.11 3.38 1.71 4.77 3.26 1.94 4.62 3.21 2.04 4.38 3.12 2.20 4.10 3.01 2.40
18.0 25.0 5.67 3.54 1.59 5.43 3.45 1.75 5.09 3.33 1.98 4.94 3.28 2.08 4.70 3.19 2.24 4.41 3.08 2.44
19.0 27.0 5.83 3.58 1.61 5.58 3.49 1.77 5.25 3.36 2.00 5.10 3.31 2.10 4.86 3.22 2.26 4.57 3.12 2.46
22.0 30.0 6.29 3.68 1.67 6.05 3.59 1.83 5.72 3.47 2.06 5.58 3.42 2.16 5.34 3.33 2.32 5.04 3.22 2.52
24.0 32.0 6.61 3.75 1.71 6.37 3.66 1.87 6.03 3.54 2.10 5.90 3.49 2.20 5.65 3.40 2.36 5.36 3.29 2.56
Correction TC SHC PI
FL -0.20 -0.11 +0.00
R45GZ7W11 + FT45GAZV1NB
+ FL45GZV1NB
Cooling capacity 400V [50Hz]
Model FT..G FL..G
AFR 11.8 10.8
BF 0.18 0.18
Indoor Outdoor temperature (°C)
EWB EDB 20 25 32 35 40 46
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
12.0 18.0 4.71 3.33 1.37 4.47 3.24 1.53 4.14 3.12 1.76 4.58 3.15 1.97 3.75 2.98 2.02 3.46 2.87 2.22
14.0 20.0 5.03 3.40 1.41 4.79 3.31 1.57 4.45 3.19 1.80 4.30 3.14 1.90 4.07 3.05 2.06 3.78 2.94 2.26
16.0 22.0 5.35 3.47 1.45 5.11 3.38 1.61 4.77 3.26 1.84 4.62 3.21 1.94 4.38 3.12 2.10 4.10 3.01 2.30
18.0 25.0 5.67 3.54 1.49 5.43 3.45 1.65 5.09 3.33 1.88 4.94 3.28 1.98 4.70 3.19 2.14 4.41 3.08 2.34
19.0 27.0 5.83 3.58 1.51 5.58 3.49 1.67 5.25 3.36 1.90 5.10 3.31 2.00 4.86 3.22 2.16 4.57 3.12 2.36
22.0 30.0 6.29 3.68 1.57 6.05 3.59 1.73 5.72 3.47 1.96 5.58 3.42 2.06 5.34 3.33 2.22 5.04 3.22 2.42
24.0 32.0 6.61 3.75 1.61 6.37 3.66 1.77 6.03 3.54 2.00 5.90 3.49 2.10 5.65 3.40 2.26 5.36 3.29 2.46
3TW00912-1D
Correction TC SHC PI
FL -0.20 -0.11 +0.03
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
TC: Total cooling capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
Caution:
TC and SHC are shown by kW
NOTES
1. Ratings shown are net capacities which include a deduction for indoor
fan motor heat
2. Shows nominal capacities
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.34 x 60 x AFR (m3/min) x (DB-EDB)/1000.
Add SHC* to SHC if SHC > TC, then TC equal SHC
4. Direct interpolation is permissible Do not extrapolate.
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
6. Add the following correction value to power input (kW) of each unit
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
3
Capacity tables
13
3
12
• Split - Sky Air • Outdoor Units
