Daikin RP71B7V1 [22/48] Capacity tables
![Daikin RP71B7T1 [22/48] Capacity tables](/views2/1783025/page22/bg16.png)
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°CWB)
EDB: Entering dry bulb temp. (°CDB)
DB*: Dry bulb temperature (°CDB)
TC: Total cooling capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
Caution:
TC and SHC are shown by kW
V1/T1: 230V [50Hz]
W1: 400V [50Hz]
NOTES
1. Ratings shown are net capacities which include a deduction for
indoor fan motor heat
2. Shows nominal capacities
3. SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
SHC* = 0.29 x 60 x AFR (m3/min) x (DB-EDB)/860.
Add SHC* to SHC if SHC > TC, then TC equal SHC
4. Direct interpolation is permissible.
Do not extrapolate..
5. Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
6. Air flow rate and BF are tabulated below.
Model FDYP
125
AFR 45
BF 0.25
RP125B7W1 + FDYP125B7V1
RP125B7T1
Cooling capacity
Outdoor
Indoor Outdoor temperature (°C)
EWB
(°C)
EDB
(°C)
20 25 32 35 40 46
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
125
12.0 18.0 11.2 10.5 3.47 10.9 10.1 3.78 10.2 9.6 4.09 9.9 9.5 4.39 9.4 9.2 4.80 8.7 8.8 5.52
14.0 20.0 12.0 10.5 3.58 11.6 10.1 3.78 10.9 9.6 4.19 10.6 9.5 4.50 10.0 9.2 4.90 9.4 8.8 5.52
16.0 22.0 12.9 10.6 3.58 12.3 10.2 3.88 11.6 9.7 4.19 11.2 9.6 4.60 10.6 9.4 5.01 9.9 8.9 5.62
18.0 25.0 13.6 10.9 3.68 13.2 10.5 3.88 12.3 10.0 4.29 12.0 9.9 4.70 11.3 9.6 5.11 10.6 9.2 5.62
19.0 27.0 13.9 11.0 3.78 13.6 10.5 3.98 12.9 10.1 4.39 12.4 9.9 4.70 11.7 9.7 5.21 10.9 9.4 5.72
19.5 27.0 14.0 11.0 3.78 13.8 10.5 3.98 13.0 10.1 4.39 12.6 10.0 4.70 11.9 9.7 5.21 11.1 9.4 5.72
22.0 30.0 15.3 11.2 3.88 14.8 10.8 3.98 14.0 10.3 4.50 13.7 10.2 4.80 13.1 10.0 5.31 12.2 9.6 5.93
24.0 32.0 16.2 11.3 3.88 15.8 10.9 4.09 14.8 10.5 4.60 14.5 10.3 4.90 13.9 10.1 5.42 13.1 9.9 6.03
3TW23382-3
•
Pair Application • R-407C • R25-60GZ7RP71-250B7
3
Capacity tables
13
3
20
• Split - Sky Air • Outdoor Units
