9 | Electrical installation
Installer reference guide
114
EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644738-1 – 2021.02
Item Description
Human Comfort Interface See:
▪ Installation and operation manual of the
Human Comfort Interface
▪ Addendum book for optional equipment
Wires: 2×(0.75~1.25mm²)
Maximum length: 500m
[2.9] Control
[1.6] Room sensor offset
WLAN module See:
▪ Installation manual of the WLAN module
▪ Addendum book for optional equipment
▪ Installer reference guide
Use the cable delivered with the WLAN
module.
[D] Wireless gateway
Bizone kit See:
▪ Installation manual of the bizone kit
▪ Addendum book for optional equipment
Use the cable delivered with the bizone kit.
[9.P] Bizone kit
for room thermostat (wired or wireless):
In case of… See…
Wireless room thermostat ▪ Installation manual of the wireless room
thermostat
▪ Addendum book for optional equipment
Wired room thermostat
without multi-zoning base unit
▪ Installation manual of the wired room
thermostat
▪ Addendum book for optional equipment
