16 | Technical data
Installer reference guide
268
EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644738-1 – 2021.02
K2R (A4P) Magnetic relay (E1H)
K3R (A1P) Magnetic relay (Y3S)
K4R (A1P) Magnetic relay (E1HC)
K10R (A1P) Magnetic relay
K11M (A1P) Magnetic contactor
K13R~K15R (A1P, A2P) Magnetic relay
L1R~L3R (A1P) Reactor
M1C Compressor motor
M1F Fan motor
PS (A1P) Switching power supply
Q1DI Earth leakage circuit breaker (30mA) (field supply)
R1~R5 (A1P, A2P) Resistor
R1T Thermistor (outdoor air)
R2T Thermistor (compressor discharge)
R3T Thermistor (compressor suction)
R4T Thermistor (air heat exchanger, distributor)
R5T Thermistor (air heat exchanger, middle)
R6T Thermistor (refrigerant liquid)
R7T Thermistor (compressor shell)
R8T Thermistor (compressor port)
R9T Thermistor (entering water)
R10T Thermistor (leaving water)
R11T Thermistor (fin)
RC (A2P) Signal receiver circuit
S1NPH High pressure sensor
S1PH, S2PH High pressure switch
S1PL Low pressure switch
T1A Current transfo
TC (A2P) Signal transmission circuit
V1D~V4D (A1P) Diode
V1R (A1P) IGBT power module
V2R (A1P) Diode module
V1T~V3T (A1P) Insulated Gate Bipolar Transistor (IGBT)
X1M, X2M Terminal strip
Y1E Electronic expansion valve (main)
Y3E Electronic expansion valve (injection)
Y1S Solenoid valve (4‑way valve)
Y2S Solenoid valve (low pressure bypass)
