16 | Technical data
Installer reference guide
269
EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644738-1 – 2021.02
Y3S Solenoid valve (hot gas bypass)
Y4S Solenoid valve (liquid injection)
Z1C~Z11C Noise filter (ferrite core)
Z1F~Z6F (A1P, A2P) Noise filter
Legend in case of W1 models:
A1P Printed circuit board (main)
A2P Printed circuit board (noise filter)
A3P Printed circuit board (leakage current)
A4P Printed circuit board (ACS)
A5P Printed circuit board (inverter)
BS1~BS4 (A1P) Push button switch
C1~C3 (A2P) Capacitor
DS1 (A1P) DIP switch
E1H Drain tube heater (field supply)
E1HHEX Plate heat exchanger heater
F1U Field fuse (field supply)
F1U~F7U (A1P, A2P) Fuse
H1P~H7P (A1P) Light-emitting diode (service monitor is orange)
HAP (A1P, A2P) Light-emitting diode (service monitor is green)
K1R (A1P) Magnetic relay (Y1S)
K1R (A2P) Magnetic relay
K1R (A4P) Magnetic relay (E1HHEX)
K2R (A1P) Magnetic relay (Y2S)
K2R (A4P) Magnetic relay (E1H)
K3R (A1P) Magnetic relay (Y3S)
K4R (A1P) Magnetic relay (E1HC)
K2M, K11M (A2P) Magnetic contactor
L1R~L4R Reactor
M1C Compressor motor
M1F Fan motor
PS (A2P) Switching power supply
Q1DI Earth leakage circuit breaker (30mA) (field supply)
R1, R2 (A2P) Resistor
R1T Thermistor (outdoor air)
R2T Thermistor (compressor discharge)
R3T Thermistor (compressor suction)
R4T Thermistor (air heat exchanger, distributor)
R5T Thermistor (air heat exchanger, middle)
