Daikin ETVH16SU23EA6V [145/296] Configuration

10 | Configuration

Installer reference guide

145

EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V

Daikin Altherma 3 H HT F

4P644738-1 – 2021.02

Explanation

–

Possible actions on this screen

Go through the list of the submenu.

Go to the submenu.

Adjust and automatically apply the desired temperature.

Item Description

Minimum temperature limit a1 Fixed by the unit

a2 Restricted by the installer

Maximum temperature limit b1 Fixed by the unit

b2 Restricted by the installer

Current temperature c Measured by the unit

Desired temperature d Turn the right dial to increase/

decrease.

Submenu e Turn or press the left dial to go to

the submenu.

10.3.6 Detailed screen with values

Example:

a bc

7.2.1

Time/date

Hours

Minutes

a Settings

b Values

c Selected setting and value

Possible actions on this screen

Go through the list of settings.

Change the value.

Go to the next setting.

Confirm changes and proceed.

10.3.7 Schedule screen: Example

This example shows how to set a room temperature schedule in heating mode for

the main zone.
