10 | Configuration
Installer reference guide
170
EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644738-1 – 2021.02
3
Additional zone
Space heating/cooling
Main zone
Room
Tank
[3] Additional zone
Setpoint screen
[3.1] Schedule
[3.2] Heating schedule
[3.3] Cooling schedule
[3.4] Setpoint mode
[3.5] Heating WD curve
[3.6] Cooling WD curve
[3.7] Emitter type
[3.8] Setpoint range
[3.9] Control
[3.A] Thermostat type
[3.B] Delta T
[3.C] WD curve type
Setpoint screen
Control the leaving water temperature for the additional zone via setpoint screen
[3] Additional zone.
See "10.3.5Setpoint screen"[4144].
Schedule
Indicates if the desired leaving water temperature is according to a schedule.
See "10.5.3Main zone"[4159].
# Code Description
[3.1] N/A Schedule:
▪ No
▪ Yes
Heating schedule
Define a heating temperature schedule for the additional zone via [3.2] Heating
schedule.
See "10.3.7Schedule screen: Example"[4145].
Cooling schedule
Define a cooling temperature schedule for the additional zone via [3.3] Cooling
schedule.
See "10.3.7Schedule screen: Example"[4145].
Setpoint mode
The setpoint mode of the additional zone can be independently set from the
setpoint mode of the main zone.
See "Setpoint mode"[4161].
