10 | Configuration
Installer reference guide
195
EPRA14~18DAV3+W1 + ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644738-1 – 2021.02
Electricity price=12.49+5
Electricity price=17.49
Price Value in breadcrumb
Gas: 4.08/kWh [7.6]=8.6
Electricity: 12.49/kWh [7.5.1]=17
10.5.8 Information
Overview
The following items are listed in the submenu:
8
Information
Installer settings
User settings
Tank
Commissioning
[8] Information
[8.1] Energy data
[8.2] Malfunction history
[8.3] Dealer information
[8.4] Sensors
[8.5] Actuators
[8.6] Operation modes
[8.7] About
[8.8] Connection status
[8.9] Running hours
[8.A] Reset
Dealer information
The installer can fill in his contact number here.
# Code Description
[8.3] N/A Number that users can call in case of problems.
Reset
Reset the configuration settings stored in the MMI (user interface of the indoor
unit).
Example: Energy meterings, holiday settings.
INFORMATION
This does not reset the configuration settings and field settings of the indoor unit.
# Code Description
[8.A] N/A Reset the MMI EEPROM
to factory default
Possible read-out information
In menu… You can read out…
[8.1] Energy data Produced energy, consumed electricity,
and consumed gas
[8.2] Malfunction history Malfunction history
[8.3] Dealer information Contact/helpdesk number
